Connectors
3.11

Camera module connector CN15

Figure 13. Camera module connector CN15
Table 28.
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
3.12

RS-232 connector CN16

Figure 14. RS-232 connector CN16 with ISP support
Table 29.
Pin number
1
2
3
32/64
Camera module connector CN15
Description
DGND
DGND
SIO_D (PB9)
AVDD (2.8V)
SIO_C (PB6)
RESET
VSYNC (PI5)
PWDN
HREF (PH8)
DVDD (1.8V)
DOVDD (2.8V)
Y7(PI7)
RS-232 connector CN16 with ISP support
Description
NC
RS232_RX (PC11)
RS232_TX (PC10)
Doc ID 018499 Rev 2
Pin number
13
14
15
16
17
18
19
20
21
22
23
24
1 2 3 4 5
6 7 8 9
Front view
Pin number
6
7
8
UM1057
Description
XCLK1
Y6(PI6)
DGND
Y5(PI4)
PCLK (PA6)
Y4(PH14)
Y0 (PH9)
Y3(PH12)
Y1(PH10)
Y2(PH11)
AGND
AGND
Description
Bootloader_BOOT0
NC
Bootloader_RESET
