UM1057
Table 19.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
2
4
6
8
10
12
14
16
Daughter board extension connector CN4
Description Alternative Function
GND -
PI6 DCMI_D6 & MC
PI4 DCMI_D5 & MC
PE0 FSMC_BL0
PB8 MII_TXD3 & MC
BOOT0 BOOT0
PB6 I2C1_SCL
PB4 TRST
PG15 User button
GND -
Smartcard_CMDVCC &
PG12
CLD_VSYNC
PG10 FSMC_NE3
PD7 FSMC_NE1
PD5 FSMC_NWE
PD3 FSMC_CLK
PD2 MicroSDCard_CMD
PD0 FSMC_D2 & CAN1_RX JP10 open
MicroSDCard_D3 &
PC11
RS232/IrDA_RX
PA15 TDI
GND -
PI7 DCMI_D7 & MC
PI5 DCMI_VSYNC & MC
PE1 FSMC_BL1
PB9 I2C1_SDA
GND -
PB7 FSMC_NL
PB5 ULPI_D7 & CAN2_RX
PB3 TDO/SWO
Doc ID 018499 Rev 2
How to disconnect with function block on
STM3220G-EVAL board
-
Remove camera module from CN15.
Disconnect motor control board from CN5.
Remove camera module from CN15.
SB16 open
-
Remove RS5
SB10 open
Disconnect motor control board from CN5.
-
Remove R103
-
Remove R150
-
Remove R128
Remove LCD board MB785 from CN19
Remove R52
-
-
-
JP22 open
Remove MicroSD card from CN6
-
-
Remove camera module from CN15
Disconnect motor control board from CN5
Remove camera module from CN15
Disconnect motor control board from CN5
-
Remove R111
-
-
JP10 open
-
Connectors
25/64
