(2) Receiver LCD instruction
: indicate key lock is set (Key lock on).
10
: show antenna A or B is receiving signal; signal is not received
11
: indicate current receiver volume.
12
: indicate device ID setting: ID number 0~255.
13
: indicate transmitter battery level; if no RF signal is received
14
up.
G: indicate current Group, 1~13
15
CH: indicate current Channel, CH1~63
Frequency indication: current operation frequency
11
10
12
13
14
9
Professional Wideband (60~75MHz) True Diversity System
.
15
(3) Rear panel
16
17
18
19
will show
Power receptacle: connect to power supply (DC15V/1000mA)
Balanced XLR MIC output
φ 6.3mm balanced output
BNC antenna socket: ANT 1 and ANT 2, set antennas vertical or sloping for better
reception.
16
Note: select MIC or LINE audio output difference:
From setup menu, set "7. OUTPUT LEVEL":
Set Line: Output level of XLR MIC output and Ø 6.3mm are identical
Set Mic: XLR MIC output level is lower than Ø 6.3mm output by "-20dB"
17
Freq.Range:
CAUTION
1856
Made in Taiwan
18
19
10
