1. System operation instructions
•
Before connecting to power, make sure the voltage marked on equipment is the same as that
on the power socket.
•
Do not place the equipment in damp and hot environment.
•
Prior to operation, please dry your hands.
•
Keep the equipment away from fire and heat source.
•
Transmitter and receiver need to be adjusted to the same "default channel" or "frequency".
2. Features
2-1 UHF PLL Broadband true diversity receiver // UF-10R
The UF-10 Wide Band Wireless Microphone System uses the latest wireless technology
can be found. Up to 75 MHz bandwidth benefits multi system application. JTS patented
REMOSET provides great convenience to project set up. Various advanced features assure a
successful performance.
•
UHF PLL True Diversity System renders 200 to 480 meters of operation distance.
•
Maximum 2400 to 3000 selectable frequencies across 60~75 MHz.
•
Maximum 12 groups, each provides maximum 60 channels. (figures vary according to
frequency band)
•
Provide 6 user-built groups, maximum 64 channels for each group.
•
Automatic search function for available frequency.
•
JTS patented function, one press key allows instant synchronous setup for
REMOSET
transmitter.
•
Adjustable squelch level.
•
JTS LCX circuit design technology effectively reduces noise interference
•
Come with antenna booster power, compatible with various external antennas.
1
Professional Wideband (60~75MHz) True Diversity System
2-2 UHF PLL Handheld transmitter // UF-10TH
•
Maximum 2400 to 3000 selectable frequencies across 60~75 MHz.
•
Phase-locked loop circuit design.
•
Extended dynamic range and smooth frequency response.
•
Tone key squelch.
•
Replaceable condenser or dynamic capsule module.
•
Hidden antenna design.
•
Lock-On function prevents signal interruption due to accidental change.
•
Adjustable transmission power between 10mW and 50 mW.
2-3 UHF PLL Body-Pack Transmitter // UF-10TB
•
Maximum 2400 to 3000 selectable frequencies across 60~75 MHz.
•
Phase-Locked Loop (PLL) synthesized tuner.
•
Extended dynamic range and smooth frequency response.
•
Adjustable transmission power
•
Tone-key squelch
•
The "lock-on" function mode prevents tampering and RF interruption.
•
4 pin mini XLR connector compatible with guitar cable and various vocal and instrument mics.
•
Adjustable transmission power between 10 mW and 50 mW
