4. Scan: scan channel
(1) Turn jog dial to "4. Scan", press Setup (or press jog dial) to
enter into scan channel screen.
#1. All Groups: scan all groups
(1) Turn jog dial to "1. All Group", press Setup (or press jog dial)
to enter into menu screen.
(2) After entering into the screen (press Exit to return to upper
menu); in "Scan All Group" press jog dial to start scanning.
(3) Scan screen indicates current percentage of completion; to
stop scan, press Exit key.
(4) After scan, automatically enter into "2. Result List" screen;
user can enter directly by selecting it on menu.
Scan result can be seen on screen; select available channel;
press Setup key to save setting; press Exit to cancel setting
#2. Result List: see scan list
Turn jog dial to 2. Result List; press Setup (or press jog dial) to
enter into menu screen to see scan result; select available chan-
nel; press Setup key to save setting; press Exit to cancel setting.
25
Professional Wideband (60~75MHz) True Diversity System
M
1. Frequency
E
2.Group/Channel
N
3.User Group
U
4. Scan
1. All Groups
2. Result List
3. Current Group
4. Return
Scan All Group
Press Setup or Enter to
To Start Scan.
Press Exit to quit.
Scan All Group
Scanning...
10%
Scan Result List
G:
1
CH: 1
Open Channel : 40
Scan Result List
G:
1
CH: 1
Open Channel : 40
#3. Current Group: scan single channel
(1) Turn jog dial to "3. Current Group"; press jog dial to enter
into menu screen.
(2) Turn jog dial to select Group first; press Setup key (or press
jog dial) to start scan.
(3) After scan, screen shows OK; press jog dial once to scan the
next channel; press Exit to return to upper menu.
#4. Return: return to main menu
Turn jog dial to "4. Return" ; press jog dial to return to menu
screen
5. Squelch: Adjust receiving sensitivity
(1) Turn jog dial to "5. Squelch", press Setup (or press jog dial) to
enter into adjustment screen.
(2) Turn jog dial to adjust squelch, ranging from 10 ~ -5; 0 is
standard, press Setup key to save setting; higher number
represents lower sensitivity; lower number represents higher
sensitivity.
6. Device ID: set device ID
(1) Turn jog dial to "6. Device ID", press Setup (or press jog dial)
to enter into ID adjustment screen.
1. All Groups
2. Result List
3. Current Group
4. Return
Scan Current Group
G:
1
CH:1
Scan Current Group
G: U1 CH:
6
OK
Press "Setup" to Save.
1. All Groups
2. Result List
3. Current Group
4. Return
M
5. Squelch
E
6. Device ID
N
7. Output Level
U
8. Antenna Power
Setup Squelch
0
M
5. Squelch
E
6. Device ID
N
7. Output Level
U
8. Antenna Power
26
