1. Frequency: set frequency
(1) Turn jog dial to "1. Frequency", press Setup (or press jog dial)
to enter into frequency adjustment screen.
(2) After entering into frequency adjustment screen, first adjust left
3 digit frequency; turn jog dial with "+/-" 1 MHz as unit change;
press jog dial to adjust right 3 digit frequency; press jog dial to
switch frequency between left and right.
(3) Adjust right 3 digit frequency; turn jog dial with "+/-"
0.025MHz as unit change; press Setup key to save setting.
2. Group/Channel: set group and channel
(1) Turn jog dial to "2. Group/Channel", press Setup (or press jog
dial) to enter into setup screen.
(2) Turn jog dial to select group "G:"; group U1~U6 are user
self-defined group/channel, which needs to be preset in "3. User
Group" before use (please refer to "3. User Group" instructions
for setup); press jog dial to set channel.
(3) Turn jog dial to adjust channel "CH:"; after adjustment, press
Setup key to save setting.
(4) If not to save setting, press Exit key twice to leave.
23
Professional Wideband (60~75MHz) True Diversity System
M
1. Frequency
E
2.Group/Channel
N
3.User Group
U
4. Scan
Setup Frequency
638
.000 MHz
G: - - CH: - -
Setup Frequency
638 .
000
MHz
G: - - CH: - -
M
1. Frequency
E
2.Group/Channel
N
3.User Group
U
4. Scan
Setup Group/Channel
G:
1
CH: 1
638.100MHz
Setup Group/Channel
G: 1 CH:
1
638.100MHz
3. User Group: user self-defined group and channel
Turn jog dial to "3. User Group", press Setup (or press jog dial) to
enter into User Group setup screen.
#1. Custom Group: self-defined group
(1) Turn jog dial to "1. Custom Group"; press jog dial to enter
into Custom Group screen.
(2) Enter into Custom Group screen; press jog dial to switch set-
ting from group (G), channel (CH), frequency in sequence; as
frequency area shows "- - - . - - -MHz", it indicates the channel
(G/CH) is not in use; turn jog dial to adjust frequency.
#2. Clear Group: clear user self-defined groups
(1) Turn jog dial to "2. Clear Group"; press jog dial to enter into
Custom Group screen.
(2) Turn jog dial to select the group to clear; then press jog dial
to clear the setting for the group; the frequency for all chan-
nels in the group will become "- - -. - - - MHz".
#3. Return: return to main menu
Turn jog dial to "3. Return"; press jog dial to return to main menu.
M
1. Frequency
E
2.Group/Channel
N
3.User Group
U
4. Scan
1. Custom Group
2. Clear Group
3. Return
Setup Group/Channel
G: U1 CH:
1
- - -,- - -MHz
1. Custom Group
2. Clear Group
3. Return
Group:
U1
Rotary to select
Push "Entry" to clear
Push "Exit" to return
1. Custom Group
2. Clear Group
3. Return
24
