(2) Turn jog dial to adjust ID, ranging 0~255; press Setup key
to save setting.
The setting will affect the use of REMOSET.
7. Output Level: set audio output level
(1) Turn jog dial to "7. Output Level", press Setup (or press jog
dial) to enter into setup screen.
(2) Turn jog dial to select Line or Mic:
- Set Line: XLR MIC Output and Ø6.3mm output volume
level is same.
- Set Mic: XLR MIC Output volume is lower than Ø6.3 mm
output by -20dB.
(3) Press Setup key to save setting
8. Antenna Power: Set power on/off provided at BNC con-
necters
(1) Turn jog dial to "8. Antenna Power", press Setup (or press
jog dial) to enter into adjustment screen.
(2) Turn jog dial to select ON or OFF to turn on or shut
down antenna booster power; press Setup key to save setting.
27
Professional Wideband (60~75MHz) True Diversity System
Setup Device ID
6 (0~255)
M
5. Squelch
E
6. Device ID
N
7. Output Level
U
8. Antenna Power
Output Levell
Line
Mic.
M
5. Squelch
E
6. Device ID
N
7. Output Level
U
8. Antenna Power
Antenna Power
ON
OFF
9. User Name: set user name
(1) Turn jog dial to "9. User Name", press Setup (or press jog
dial) to enter into User Name setup screen.
(2) Turn jog dial to select desired character; after confirmation
press jog dial to go to next character setup; after setup press
Setup key to save setting.
A user name consists of 10 characters at maximum.
a. Contrast: adjust screen contrast
(1) Turn jog dial to "a. Contrast", press Setup (or press jog dial) to
enter into setup screen.
(2) Turn jog dial to adjust screen contrast; after confirmation
press Setup key to save setting; higher number represents
darker color; 7 adjustable levels.
b. Key Lock: set key lock
(1) Turn jog dial to "b. Key Lock", press Setup (or press jog dial)
to enter into setup screen.
(2) Turn jog dial to select "Lock On"; after confirmation press
Setup key to save setting; "Lock On" can lock all panel keys to
prevent accidental touch except " Setup" key.
M
9. User Name
E
a. Contrast
N
b. Key Lock
U
c. Exit
User Name
JTS UF-10R
Char:1/10
10 characters
Indicate which
available
character currently
is set
M
9. User Name
E
a. Contrast
N
b. Key Lock
U
c. Exit
Setup Contrast
4/7
M
9. User Name
E
a. Contrast
N
b. Key Lock
U
c. Exit
Setup Key Lock
Lock On
Lock Off
28
