Rev J, October, 2010

Introduction

This operations manual describes the Intercomp Model CW250 specifications, detailed
operating procedures, and calibration.
This manual is separated into several sections, each containing information on a
different aspect of the platform. The specifications outline the design parameters for the
scale. The detailed operation section outlines the correct use of the scale for most
applications. The calibration section explains how to set the platform's adjustments.
Features
lb or kg programmable readout.
Ability to display total weight.
Accumulating total function.
Auto zero tracking automatically corrects zero-weight display shifts.
5½ digit, 1 inch LCD readout, with automatic back lighting.
5-15 VDC and 120 VAC 60 Hz power sources standard.
RFI/EMI protection.
Low battery detection with automatic shutoff to protect batteries.
Built-in self-diagnostics to check: Load cells, Memory, Display, AD converter, and
Power supply.
Weigh pads manufactured from high strength aluminum alloys.
OPTIONS
220V / 50Hz charging transformer
24" x 24" ramp (100181)
cast aluminum
15" x 15" ramp (100330)
cast aluminum
Battery operated tape printer (100090)
Transport wheels (100183)
2 per platform.
Remote indicator (100184)
Indicator with pedestal.
Remote indicator (100184)
Indicator for use on floor or wall.
