Serial Output Setup

There are four different serial output modes for the CW250, "on-demand", "continuous",
"accumulating print" wheel axle format, and "accumulating print" standard format. See
below for more information on these modes.
To setup the serial output mode: Press the PRINT/ACCUMULATE and ZERO
buttons simultaneously until the display shows "b.LitE", Press the PRINT/
ACCUMULATE button to scroll through the menu (12 times) until the display shows
"Prt t". Press the PRINT/ACCUMULATE button once to display setting number. Set
print mode to the number of the print mode wanted by using the LOCAL/TOTAL button
to increment and the ZERO button decrement the number. .
Communication Mode
Accumulating Print Axle
Accumulating Print Standard
Notes: For best results, only set one scale to '1, '2 or '3. This should also be
the scale you are printing from. '0' is the default setting.
Press the PRINT/ACCUMULATE button. Now the display will display "PbAUd". Press
the PRINT/ACCUMULATE button to change the baud rate set, press the LOCAL/
TOTAL or the ZERO button to cycle through the baud rates available. The baud rates
available are: 1200, 2400, 4800, 9600, 19200, 38400, 57600, and115200. When the
desired baud rate is displayed, press the PRINT/ACCUMULATE button. The baud rate
only needs to be set on the scale doing the printing. The settings are saved once
PRINT/ACCUMLATE is pressed to advance the menu, and the scale can then be
turned off to exit the Mode Menu.

On-Demand

The weight is transmitted every time the PRINT/ACCUMULATE key is pressed.
Press PRINT/ACCUMULATE to print either the local or total weight (depending
on the local/total setting of the scale). This is the default print mode.

Continuous

The CW250 automatically and continuously outputs the weight at a rate of about
once per second.
On-Demand
Continuous
Page 10 of 29
Rev J, October, 2010
Setting
0
1
2
3
