- Page 1 Intercomp SWII Users Manual Intercomp Co. 3839 County Road 116 Minneapolis, MN 55340 (763)-476-2531 1-800-328-3336 Fax 763-476-2613 www.intercomp-racing.com Manual #: 700036-H...
-
Page 2: Table Of Contents
LEFT FRONT...............................7 RIGHT FRONT ..............................7 LEFT REAR .................................7 RIGHT REAR ...............................8 FRONT TOTAL..............................8 REAR TOTAL...............................8 CROSS .................................8 TOTAL .................................8 ..............................8 OWER ATTERIES SERIAL OUTPUT...............................9 : ..........................9 ONNECTOR ESIGNATIONS .................................9 ROTOCOL ................................10 RINT ICKET ERROR MESSAGES..............................11 HOW TO REACH INTERCOMP SERVICE ......................12... -
Page 3: Introduction
SWII Users Rev H, June 2004 Introduction This manual contains specifications and operating instructions for Intercomp's SWII Scale System. Specifications Controls General: On, Off, %/WGT, TEST/ZERO, Left Front, Right Front, Left Rear, Right Rear Channel selection: Any combination Display: 4 digit, LCD (0.5”) -
Page 4: Physical
This option allows you to drive the car onto the pads in the case that you are not using a setup rack or jacking the car up. 220 VAC/ 50 Hz Power Pack (100546) 220 VAC plug-in transformer provides direct power to the SWII indicator. System Carrying Case (100056) Holds the 4 platform scales, indicator, cables, and manual. -
Page 5: Setup
SWII Users Rev H, June 2004 Setup System System setup configuration 1. Place the four pads near their appropriate car tire: LF by left front, RF by right front and so on. 2. Connect one end of each cable to a pad: LF-Red cable, RF-Green cable, LR-White cable, RR-Black cable. -
Page 6: Operations
SWII Users Rev H, June 2004 Operations Display Left Front Right Front 8888 Low Battery Selected % Left Rear Right Rear Controls Turns system on. Turns system off. -
Page 7: Wgt
If pressed during normal weighing mode, the system will zero all four pads. To zero a specified pad, press and hold the corresponding key (LF, RF, LR, RR) and press zero. This key is also used to set calibration data (see SWII Service Manual). -
Page 8: Right Rear
Power / Batteries You may use 6 rechargeable Nickel-Cadmium ‘AA’-cells or 6 standard alkaline ‘AA’ cells in the SWII system. WARNING: Do not plug the charger in while there are standard alkaline cells inside. This could result in damage to the batteries and your scale. -
Page 9: Serial Output
SWII Users Rev H, June 2004 Serial Output Connector Pin Designations: PT Connector A: NC B: NC C: Ground (- Charging Voltage) D: NC E: +Charging Voltage F: NC G: TXD H: Ground (signal) Protocol The serial output is RS-232 and in the following format:... -
Page 10: Print Ticket
SWII Users Rev H, June 2004 Print Ticket The print ticket is in the following format: <cr><lf> SW,I,,SCALES<cr><lf> BY,INTERCOMP<cr><lf> <cr><lf> LF[,,xxxxx<cr><lf> RF[,,xxxxx<cr><lf> LR[,,xxxxx<cr><lf> RR[,,xxxxx<cr><lf> <cr><lf> TOTAL, , xxxxx<cr><lf> ,,,,%,,xxx.x<cr><lf> <cr><lf> END,PRINT<cr><lf> <cr><lf> Item Meaning Note LF,RF,LR,RR Pad weights TOTAL Total selected weight... -
Page 11: Error Messages
SWII Users Rev H, June 2004 Error messages The weight is too large to fit on the display. dise This message will blink if weight present on the pad exceeds the pads capacity, or the pad is not plugged in, or the pad may have failed. -
Page 12: How To Reach Intercomp Service
Rev H, June 2004 How to reach Intercomp Service Things to know: 1. The service is for a SWII scale system. 2. When did you purchase your scale? 3. What is your serial number? 4. Whom did you purchase the scale through?
