Using Accumulated Total

The CW250 platforms can be used separately, in pairs, or in groups to measure a
support load or the total weight in one measuring procedure.
To use the Accumulated Total feature, the scales need to be numbered correctly and
the scale you intend to print from or display the accumulated total must have it's print
mode set to one of two 'Accumulating Print' modes. See the "Totalizing Setup" and
"Serial Output Setup" sections for details.

Accumulating Print Axle

Press the PRINT/ACCUMULATE button to add the current total weight to the
accumulated total weight. At the same time, a print ticket will be generated
(assuming you have a printer in the system). The print ticket format is in respect
to a vehicle's individual wheels and axles or a standard weight accumulation
mode.
For example wheel and axle, think of "WHL 1" as scale 1 and "AXL 1" as the total
weight of scale 1 and scale 2. The following print ticket example is a 4 scale
system:
PRINT / ACCUMULATE
button has been pressed
PRINT / ACCUMULATE
button has been pressed
Once a successful accumulation has occurred, press the LOCAL/TOTAL button
to toggle the display through the current local weight, current total weight,
accumulated total, and the number of accumulations that make up the total.
.
WHL 1:
AXL 1:
WHL 3: 10110
AXL 2:
SUBTOTAL GRP 1: 35040
ACCUM TOTAL: 35040
WHL 1: 10110
AXL 1:
WHL 3:
AXL 2:
SUBTOTAL GRP 2: 39480
ACCUM TOTAL: 74520
