Operations
The control panel has a liquid crystal display (LCD) screen and four control switches.
Display Description
The display is a Liquid Crystal Display unit, providing one line of 5 1/2 digits. The
screen shows the weights read from the pad. The TOTAL icon indicates measurement
mode as in the table below the CW250 display. Information displayed includes
indicators for both "lb" and "kg", a segment bar to show battery charge level, error
conditions and set-point indicators when set-point thresholds are reached. The display
contains an automatic backlight for use in low-light conditions.
CW250 scale
Diagram: CW250 display
Mode status
TOTAL not lit
TOTAL lit
TOTAL flashing
Page 5 of 29
Setting
Local
Total
Accumulated Total
CW250, Users
Rev J, October, 2010
