Calibration menu
To initiate calibration simultaneously press the PRINT/ACCUMULATE and ZERO
buttons. The display will show "StEP", if it does not, the calibration strap is incorrectly
placed to allow calibration. Return to 'Calibration Enable Jumper' section to verify
correct setting. Press the PRINT/ACCUMULATE button to access the parameter
setting.
At times it will be necessary to enter up to a five digit number. When this is necessary
the current number will be displayed with the right most digit flashing. The flashing digit
may be incremented by pressing the LOCAL/TOTAL button. To move one digit to the
left, press the ZERO key. When you have finished entering a number press the PRINT/
ACCUMULATE button. The settings are saved once PRINT/ACCUMLATE is pressed to
advance the menu, and the scale can then be turned off.
Step
Function
StEP
skip
U. EnA
Unit enable
bP 1
grad break point 1
bP 2
grad break point 2
bP 3
grad break point 3
AdC.rt
ADC rate
A2t
AZT (auto zero tracking)
2Er0.r
Zero range
grAd
graduation size
SAVE
CAP
capacity
LL-01
No weight applied
First weight
-
HH
01
First weight
-
LL
01
Second weight
-
HH
02
Second weight
-
LL
02
Third weight
-
HH
03
LL-03
Third weight
HH-04
Fourth weight
LL-04
Fourth weight
10 points available to enter
Note
000= no skip
001= skip to Weight Calibration
Yes or no
Enter weight
Enter weight
Enter weight
0 or 1
1 d, 3 d, .5 d, oFF, or.6 d
0= off, 1= 1%, 2= 2%, 3= 5%,
4 = 1%
0.02, 0.05, 0.1, 0.2, 0.5, 1, 2, 5,
10, 20, 50, or 100
Displays for 1 sec and advances
Enter scale capacity
Enter first weight
Load first weight
Enter second weight
Load second weight
Enter third weight
Load third weight
Enter fourth weight
Load fourth weight
3 minimum recommended
Page 21 of 29
CW250, Users
Rev J, October, 2010
Default
000
YES
00000
00000
00000
1
1 d
0
d
1
20000
