Error Messages

Message Meaning
EEPE
EEPROM failure. Scale will require recalibration
AD 1 AD converter failure. Circuit board may need to be repaired or replaced
LCbxx
Self test shunt-current circuitry has detected one or multiple load cell
errors. A load cell may have failed or there is a bad connection. "XX"
shows which cell or connection has failed: xx = 1-8 (single digit) if
there is a single load cell failure, or xx = 2-digit hex code if multiple
cells failed. (Examples: "LCb 2" = load cell # 2 error, "LCb0F" = load
cells #1-#4 errors)
LC xx
Run-time overload limit circuitry has detected one or multiple load cell
errors. A LC may have failed or there is a bad connection. "xx" shows
which cell or connection has failed: xx = 1-8 (single digit) if there is a
single load cell failure, or xx = 2-digit hex code if multiple cells failed.
(Examples: "LC 2" = load cell # 2 error, "LC 0F" = load cells #1-#4
errors)
Lo.bat
Low battery. Replace the battery or connect the charger if using
rechargeable batteries. (Warning: Do not charge alkaline cells)
CAP
Overcapacity. Reduce load to scale
Zero.r Zero range error. Scale tried to zero off a load outside the range
specified in the zero range setting. Remove any load applied and
press zero.
disp Display error. Number is too large to fit on the display.
C0p or
Diagnostic power-up messages. These won't affect normal operation
and can typically be ignored.
CLOC
AC.Err
This indicates that certain conditions for accumulation have not been
met and that the attempted scale accumulation was rejected. The
scale will not accumulate and will display the error message "Ac.Err" if
the current weight is negative, zero, or if the weight is in motion. Also,
only one accumulation is allowed while weight is still on the scale(s).
The weight should be temporarily removed in between accumulations.
See the "Accumulating Print Axle" section for details.
