Setting the Calibration Parameters

1. At any point in the following steps, data will be retained by the scale at the step
completed if the power is cycled off. To initiate calibration simultaneously press the
PRINT/ACCUMULATE and the ZERO buttons. The scale shows "StEP". Press the
PRINT/ACCUMULATE button. The scale shows "000" with the far right number
flashing. To go through all of the calibration parameters, press PRINT/
ACCUMULATE with the display showing "000". To skip the first 8 calibration
parameters and proceed to step 10 enter "001" or "002". See Diagnostics section for
additional codes available. Use the LOCAL/TOTAL button to increment and the
ZERO button to decrement the number. Press the PRINT/ ACCUMULATE button
when the desired number is displayed.
2. The display shows "U. EnA" if proceeding through all parameters. Press the PRINT/
ACCUMULATE button. The display will read "YES". Pressing LOCAL/TOTAL or the
ZERO button will toggle the display to "no". With the display showing "YES", press
the PRINT/ACCUMULATE button.
3. The display now shows "bP 1". Press the PRINT/ACCUMULATE button. The
display will read the current setting with the far right number flashing. Use the
LOCAL/TOTAL button to advance the number and the ZERO button to move the
number flashing to the left. When the desired graduation break point is displayed
press the PRINT/ ACCUMULATE button.
4. The display shows "bP 2". Press the PRINT/ACCUMULATE button. Repeat the
process in step 3 for graduation break point 2. When the desired graduation break
point is displayed press the PRINT/ACCUMULATE button.
5. The display shows "bP 3". Press the PRINT/ACCUMULATE button. Repeat the
process in step 3 for graduation break point 3. When the desired graduation break
point is displayed press the PRINT/ACCUMULATE button.

Multiple Graduation Break Points

The CW250 has the ability to have multiple graduation values set. Following is
an example of setting graduation break points. Example:
Grad = Initial graduation equals by 0.1 lb
Cap = 10000 (Capacity equals 10,000 lb)
bP 1 = 1000
bP 2 = 2000
bP 3 = 5000
