6.

Carrier Specific Information

Each cellular provider uses a different PRI file that needs to be programmed into the modem
for the modem to register properly on their cellular network and connect. These PRI files are
typically programmed into the modem by the manufacturer of the RF module. The following
sections list different carriers and the requirements for activating modems on their
networks. Cellular providers will (where applicable) supply username and password formats
for making EVDO calls. Logic Data Systems modems support the service provisioning
features called Over-the-Air Service Provisioning (OTASP) and Over-the-Air Parameter
Administration (OTAPA). OTASP occurs when a user initiates a call to the service provider.
No further commands are (typically) required to provision the modem. For example, a user
with a new modem/phone without service programming data can call the service provider's
special OTASP number to have the device programmed without physically taking it to the
service provider. OTAPA occurs when the network initiates a call to the modem and
programs it without any user intervention. OTAPA is typically used when the service
provider decides to update information on many cellular devices at the same time.
NOTE: L-5500 radio modems are carrier specific, you must specify the carrier you will be
using when ordering. A unit purchased for one carrier cannot be activated on any other
carrier.
Generally, you will not be able to provision a device if you are not in your home network
area. You will also need to make sure that you have sufficient signal strength to perform
provisioning.
6.1.

Verizon Wireless

Before starting the OTA process, ensure that you have a strong enough signal for cellular
communication.
When you activate a contract with Verizon, Verizon will assign a 10 digit MDN/MIN number
to your module's ESN. When this is done, you are ready to OTA the module. Verizon
activation is done by submitting an OTA command of *22899 to the Verizon network. This
command is entered by default into the OTA command box on the "WAN Cellular Page". It
should not be necessary to modify this command, simply select OTASP, click "Submit" and
allow the activation to complete. This process may take several minutes. This command is
also used to update the PRL file. When the OTA is complete, the MDN provided by Verizon
should be displayed on the home page.
6.2.

Bell Mobility

Activation on the Bell mobility network requires manual entry of the MDN, MIN and Unlock
code. Bell will provide these numbers when you initiate your data contract with them. In
most cases, the MDN and MIN will be the same number. On the WAN Cellular page, enter
the MDN, MIN and Unlock code and click "Submit". The activation process will occur
Page 56
