During Operation: Reports are delayed for 30 seconds after loss of cellular connectivity is
detected.
Select "Local (1 sec)" if every GPS report is required or "Remote (aavl)" for GPS reports to
be sent out based on the AAVL settings (see AAVL settings).
Note: GPS Report format is set in the "TCP Server Format" pick lists on the GPS web page.
5.10.1.2. Garmin Messaging
Enables transfer of navigation and messaging functions to an attached Garmin navigation
device for automated dispatch and messaging. Requires subscription to Logic Data Systems
Fleet Management System.
5.10.1.3. Road Safety RS-3000
Allows transmission of Road Safety data using the cellular data network. When selected,
ensure the L-5500 COM port is connected to COM3 or COM4 on the RS-3000 black box
using a straight through serial DB9M to DB9F cable.
NOTE: When using the L-5500 in conjunction with the Road Safety RS-3000, a static IP
address is highly recommended.
5.10.1.4. Serial Over TCP/UDP
Enables the L-5500 to act as a remote virtual serial port for communicating with PCs using
TCP.
Baud rate: Baud rate of connected serial device.
Idle Disconnect Timeout: When no traffic has been sent or received during this period,
the socket is closed and reset to allow subsequent connections to be established.
Remote Host: Remote destination of where packets are transmitted.
Port: Local TCP port to listen for client connections.
Control Port (TCP Only): TCP Port used for control and monitoring of the serial port by
the remote application.
Pad Mode: Currently always set to tcp.
