Status: indicates if the device has an established connection to the WAN. Status is UP or
DOWN
IP Address: WAN IP address of the L-5500 unit. Remote access for the device requires
entering this address into a browser. The WAN IP Address is assigned by the cellular carrier
and will be dynamic unless a static address is specifically requested
Warning: Be aware of the dynamic nature of the WAN IP Address as it can affect related
applications.
Subnet Mask: This subnet mask is assigned by the carrier and is not configurable by the
user.
P-t-P: WAN IP address of the network access point of the cellular carrier
CDMA Connection
Service Type: Service Type indicates the type of service connection. The L-5500 radio
modem will automatically connect to the most advanced service available and will fall back
to other networks (such as 1xRTT) when EV-DO Rev A is not available.
Roaming Status: Roaming Status indicates the unit roaming status. Status is ROAMING,
NOT ROAMING, or a carrier specific value.
ESN: Electronic Serial Number is assigned to the cellular modem at the factory. This
number must be provided to the carrier to activate the module.
Signal Strength: Receive Signal Strength Indication indicates the strength of the network
signal with both a numerical value and a good/medium/poor message.
Call End Reason: Code indicating the reason for a call ending.
5.3.

Cellular WAN Parameters

This page contains the provisioning information and the carrier activation settings. For more
information on the procedure for carrier activation, see "Provisioning the L-5500 Radio
Modem".
5.3.1.

Status

WAN Status information available (Figure 11):
ESN: Electronic Serial Number is assigned to the cellular modem at the factory. This
number must be provided to the carrier to activate the module.
MEID: Mobile Equipment Identifier is used by the cellular carrier as the means to identify
the cellular module. This is the identifier used to set up the user account with the cellular
provider.
IMEI: International Mobile Equipment Identity is the serial number of the GSM module in
the modem.
Page 21
