5.5.1.1.
Configuration
Wireless Mode
Disable: The WiFi interface is disabled
Client: The WiFi interface operates in Client mode
Access Point: The WiFi interface operates in Access Point mode
5.5.1.2.
Status
IP Address: IP address assigned to the WiFi interface
Subnet Mask: IP Subnet Mask assigned to the WiFi interface
SSID: Name of the wireless local area network
Authentication: Authentication method currently used (Example: Open, Shared,
WPANONE, WPA-PSK, WPA2-PSK)
Encryption: Encryption method currently used
Channel: Channel currently used (Auto or 1-11)
State: Current state of the WiFi interface (Disabled, Ready if in Access point Mode, or Not
Connected, Scanning, and Connected if in Client Mode)
RSSI: Received Signal Strength Indicator (displayed in Client Mode only)
5.5.2.
WiFi (WLAN) - Wireless Settings (Client)
The L-5500 can be configured for up to 20 access points.
Note: All access points must run a DHCP server.
In wireless client mode, the L-5500 unit will try to connect to the Access Point with the
strongest signal on the list. When the L-5500 unit connects to an access point, it starts a
DHCP client service. The DHCP server running on the access point must provide an IP
address, netmask, and gateway to the L-5500 unit. When the WiFi client is connected to a
WiFi access point, the default route is set to point to the gateway address obtained by the
DHCP client.
Page 29
