Laser Product Label
The following label or equivalent is located on the surface of the laser module.
Laser Information
Laser Type
Wave Length
Divergence Angle
Output Power
Numerical Aperture
Compaq Confidential – Need to Know Required
Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments:
Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM
This label indicates that the product
is classified as a CLASS 1 LASER
PRODUCT.
Semiconductor GaAIAs
770-860 nm
minimum 15 degrees
·
Less than 0.2 mW /10,869 W
m
0.45 +/- 0.04
Regulatory Compliance Notices B-5
-2
-1
sr
