Compaq SW5425 Specification

M
O D E L S
Compaq SW5425 Desktop
Gigabit Ethernet Switch
24 10/100Base-TX ports + one
1000Base-SX GBIC port
338376-B21
Compaq delivers
Gigabit speed for
desktop switching and
high-performance
workgroup applications
with the Compaq
SW5425
11-101 DA-10090-01-001 — 9.13.1999
Q S
UICK PECS
. .
High Availability/High-Performance Switch
. .
. .
. .
Several forces are driving the need for high speed LANs today - The growth of the Internet, re-centralization of
. .
. . corporate computing, and network-centric applications. Applications today such as transaction processing, voice,
. .
video, graphics, and Internet access are bandwidth consuming, server-oriented, and require higher speed networks.
. .
. .
They demand high performance and ready availability for the desktop user.
. .
. .
The Compaq SW5425 Desktop Gigabit Ethernet Switch is poised to meet these demanding needs at the desktop with
. .
. .
Gigabit switching capability. Users can employ the 24 10Base-T/100Base-TX ports that autosense for 10/100 Mbps
. .
. . operation and half- or full-duplex operation. The single Gigabit Ethernet port can accommodate high performance
. .
applications with fail-over achieved through the redundant port. The SW5425 switch is capable of non-blocking, line
. .
. .
rate performance on all ports when configured as a Layer 2 switch or as a Layer 3 IP router.
. .
. .
. .
. .
E U
A S E O F S E
. .
. .
. .
Auto-negotiation
. .
. .
. . Each RJ-45 switched port on the Compaq SW5425 automatically senses if it is a 10 Mbps or a 100 Mbps network
. .
connection, thus allowing for seamless communication among the Ethernet family of protocols.
. .
. .
. .
Hot-swappable Gigabit Interface Connector
. .
. .
The standard Gigabit Ethernet port, a hot-swappable 850nm 1000Base-SX GBIC module, can be replaced with a
. .
. .
1000Base-LX GBIC for networks spanning longer distances.
. .
. .
. .
. .
P
E R F O R M A N C E
. .
. .
. .
More Power
. .
. .
. .
A massive backplane provides more than enough raw bandwidth to support non-blocking operation. This means that
. .
all ports transmit and receive traffic at line rate (full-duplex operation) without over-subscribing the switch.
. .
. .
Dynamically assigned buffer memory (2 MB) ensures that even during peak traffic conditions no data is lost.
. .
. .
. .
Load Sharing/Port Aggregation
. .
. .
. . The Compaq SW5425 can be configured to use a group of ports to carry traffic in parallel between switches. This
. .
creates higher throughput and resilience.
. .
. .
. .
Quality of Service (QoS)
. .
. .
. .
QoS dedicates bandwidth to traffic types, allowing network managers to shape network traffic and provide needed
. .
bandwidth to business-critical applications.
. .
. .
. .
. .
N M
. .
E T W O R K A N A G E M E N T
. .
. .
Compaq Networking Management Software (CNMS)
. .
. .
. .
CNMS provides an intuitive graphical user interface making installation and monitoring of the Compaq SW5425
. .
. .
effortless.
. .
. .
Easy to use TELNET and Web-based management are provided for hands-on management and configuration. The
. .
Compaq SW5425 can be graphically managed under powerful management platforms such as HP OpenView, IBM
. .
. .
NetView, SunNet Manager, and Novell ManageWise using WinManager, a product from Compaq partner Ordinox
. .
. .
Networks.
. .
. .
Remote Monitoring (RMON) Groups 1, 2, 3, 9
. .
. .
. .
The SW5425 supports four of the nine groups of remote monitoring — network traffic statistics, history, alarms, and
. .
. . events.
. .
. .
Virtual LANs (VLANs)
. .
. .
. .
Setting up VLANs eases many time-consuming tasks of network administration while increasing efficiency in network
. .
. .
operations. By tagging each frame with information about which virtual LAN it belongs to, users can be connected to
. .
any LAN segment regardless of their physical location. The SW5425 uses the IEEE 802.1Q draft standard and
. .
. .
supports up to 256 VLANs. The switch also supports protocol and port based VLANs that are not covered in the
. .
. .
standard
. .
. .
. .
. .
. .
Compaq SW5425
Desktop Gigabit
Ethernet Switch
