2-2 Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide
Compaq Rack Warning
Hub Warning and Precaution
Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments:
Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved
Figure 2-1. Hub 12 installed in a Compaq rack
WARNING: To reduce the risk of personal injury or damage to the equipment:
Extend the leveling jacks to the floor and ensure that the full weight of the
rack rests on the leveling jacks.
Ensure that the stabilizing feet are attached to the rack in a standalone
rack installation.
Couple together racks in multiple rack installations.
Extend only one component at a time. A rack may become unstable if
more than one component is extended for any reason.
WARNING: To reduce the risk of personal injury or damage to the equipment:
Do not disable the power cord grounding plug. The grounding plug is an
important safety feature.
Plug the power cord into a grounded (earthed) electrical outlet that is
easily accessible at all times.
Disconnect power from the hub by unplugging the power cord from either
the electrical outlet or from the back of the hub.
Compaq Confidential – Need to Know Required
On: 4/16/99 8:19 AM
