Grounding Methods

Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments:
Part Number: 340662-002 File Name: e-appa Electrostatic Discharge.doc Last Saved On: 4/16/99 8:26 AM
There are several methods for grounding. Use one or more of the following
methods when handling or installing electrostatic-sensitive parts:
Use a wrist strap connected by a ground cord to a grounded workstation
or computer chassis. Wrist straps are flexible straps with a minimum of
1 megohm ± 10 percent resistance in the ground cords. To provide
proper ground, wear the strap snug against the skin.
Use heel straps, toe straps, or boot straps at standing workstations. Wear
the straps on both feet when standing on conductive floors or dissipating
floor mats.
Use conductive field service tools.
Use a portable field service kit with a folding static-dissipating work
mat.
If you do not have any of the suggested equipment for proper grounding, have
an Authorized Compaq Reseller install the part.
NOTE: For more information on static electricity, or assistance with product installation,
contact your Authorized Compaq Reseller.
