Rear Panel Components
Ref. Component
1
Power LED
2
Fault LED
3
Reset Button
4
GBIC LED (typical LED for
all 12 ports)
5
Bypass Port LED (typical
LED for all 12 ports)
6
AC Power Connector
Compaq Confidential – Need to Know Required
On: 4/16/99 8:19 AM
Table 2-1
Status Indication or Explanation of Use
ON Illuminates green to indicate unit is ON.
OFF Unit is OFF or there is a power failure.
See Chapter 3, "Troubleshooting," for
troubleshooting suggestion.
ON Hub is running a self test. If LED remains
on longer than 60 seconds, indicates unit
failure. See Chapter 3,
"Troubleshooting," for troubleshooting
suggestions.
OFF No faults detected.
Press to run self test or to reset the hub.
ON Illuminates green when a GBIC Module is
present. See Chapter 3,
"Troubleshooting," for troubleshooting
suggestions.
OFF GBIC Module is not present or port is not
functioning properly.
ON Port is bypassed. Illuminates amber
when a connected port is not
participating in a loop operation. Refer to
Chapter 3, "Troubleshooting," for
troubleshooting suggestions.
OFF Port is not bypassed.
100 - 240 VRMS @ 50 - 60 Hz line
voltage
