To prevent damaging the system, be aware of the precautions you need to

follow when setting up the system or handling parts. A discharge of static

electricity from a finger or other conductor may damage system boards or

other static-sensitive devices. This type of damage may reduce the life

expectancy of the device.

To prevent electrostatic damage, observe the following precautions:

Avoid hand contact by transporting and storing products in static-safe

containers.

Keep electrostatic-sensitive parts in their containers until they arrive at

static-free workstations.

Place parts on a grounded surface before removing them from their

containers.

Avoid touching pins, leads, or circuitry.

Always be properly grounded when touching a static-sensitive

component or assembly.
