StorageWorks Fibre Channel
Storage Hub 12
Installation Guide
First Edition (June 1999)
Part Number 340662-002
Compaq Computer Corporation
Compaq Confidential

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StorageWorks and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq StorageWorks

Summary of Contents for Compaq StorageWorks

  • Page 1 StorageWorks Fibre Channel Storage Hub 12 Installation Guide First Edition (June 1999) Part Number 340662-002 Compaq Computer Corporation Compaq Confidential...
  • Page 2 MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. © 1999 Compaq Computer Corporation.

  • Page 3: Table Of Contents

    Rack-Mounting or Desktop Installation ..............2-3 Tools Needed ......................2-3 Installing the Rack Mounting Hardware for a Compaq Rack Installation ....2-4 Locating the Rack Mounting Hardware ............2-4 Identifying the Rack Mounting Rails and the Chassis Slide Rails....2-5 Attaching the Rack Mounting Rails to the Rack..........
  • Page 4 Appendix D Specifications Compaq StorageWorks Fibre Channel Storage Hub 12...........D-1 Index Compaq Confidential Need to Know Required Writer: Susan Caesar Project: StorageWorks Fibre Channel Storage Hub 12 Comments: Part Number: 340662-002 File Name: a-frnt.doc Last Saved On: 6/14/99 2:37 PM...

  • Page 5: About This Guide

    When you are instructed to enter information, type the information and then press the Enter key. Compaq Confidential Need to Know Required Writer: Susan Caesar Project: StorageWorks Fibre Channel Storage Hub 12 Comments: Part Number: 340662-002 File Name: a-frnt.doc Last Saved On: 6/14/99 2:37 PM...

  • Page 6: Symbols In Text

    Compaq Confidential Need to Know Required Writer: Susan Caesar Project: StorageWorks Fibre Channel Storage Hub 12 Comments: Part Number: 340662-002 File Name: a-frnt.doc Last Saved On: 6/14/99 2:37 PM...

  • Page 7: Rack Stability

    Compaq Confidential Need to Know Required Writer: Susan Caesar Project: StorageWorks Fibre Channel Storage Hub 12 Comments: Part Number: 340662-002 File Name: a-frnt.doc Last Saved On: 6/14/99 2:37 PM...

  • Page 8: Compaq Website

    Outside North America, call the nearest Compaq Technical Support Phone Center. Telephone numbers for world wide Technical Support Centers are listed on the Compaq website. Access the Compaq website by logging on to the Internet at http://www.compaq.com. Be sure to have the following information available before you call Compaq:...

  • Page 9: Product Summary

    Flexibility - adheres to the ANSI FC-AL standard Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: b-ch1 Product Summary.doc Last Saved On: 4/16/99 8:05 AM...

  • Page 10: Functions

    Channel Storage Hub 12 option kit. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: b-ch1 Product Summary.doc Last Saved On: 4/16/99 8:05 AM...

  • Page 11: Overview Of Installing The Compaq Storageworks Fibre Channel Storage Hub

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 12: Compaq Rack Warning

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 13: Installation Sequence

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 14: Installing The Rack Mounting Hardware For A Compaq Rack Installation

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 15: Identifying The Rack Mounting Rails And The Chassis Slide Rails

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 16: Attaching The Chassis Slide Rails To The Hub

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 17 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 18: Installing The Hub Into The Rack

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 19 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 20 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 21 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 22: Installing The Rubber Feet For A Desktop Installation

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 23: Identifying The Rear Panel Components

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 24 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 25: Hub

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 26 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 27: Connecting The Power Cord And Performing A Self Test

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...
  • Page 28 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: c-ch2 Overview of Installing the Compaq StorageWorks Fibre Channel Storage Hub 12.doc Last Saved On: 4/16/99 8:19 AM...

  • Page 29: Troubleshooting Guidelines

    4. Make sure that both ends of each Fibre Channel cable are connected to active, powered, FC-AL devices. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: d-ch3 Troubleshooting.doc Last Saved On: 4/16/99 8:25 AM...

  • Page 30: Troubleshooting With The Leds And The Reset Button

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: d-ch3 Troubleshooting.doc Last Saved On: 4/16/99 8:25 AM...

  • Page 31: Performing A Self Test After The Initial Power-Up

    Figure 3-1. Checking the power LED and the fault LED Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: d-ch3 Troubleshooting.doc Last Saved On: 4/16/99 8:25 AM...
  • Page 32 Figure 3-3. Bypass port LED illuminates when port is not participating on loop. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: d-ch3 Troubleshooting.doc Last Saved On: 4/16/99 8:25 AM...

  • Page 33: Electrostatic Discharge

    Always be properly grounded when touching a static-sensitive component or assembly. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: e-appa Electrostatic Discharge.doc Last Saved On: 4/16/99 8:26 AM...

  • Page 34: Grounding Methods

    Authorized Compaq Reseller. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: e-appa Electrostatic Discharge.doc Last Saved On: 4/16/99 8:26 AM...

  • Page 35: Regulatory Compliance Notices

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM...

  • Page 36: Class A Equipment

    Règlement sur le matériel brouilleur du Canada. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM...

  • Page 37: European Union Notice

    Japanese Notice Taiwanese Notice Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM...

  • Page 38: Laser Compliance

    This device is classified as a Class 1 laser product as defined by IEC 825. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM...

  • Page 39: Laser Product Label

    Numerical Aperture 0.45 +/- 0.04 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: f-appb Regulatory Compliances Notices.doc Last Saved On: 4/16/99 8:27 AM...

  • Page 40: Power Cord Set Requirements

    Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installtion Guide Comments: Part Number: 340662-002 File Name: g-appc Power Cord Set Requirements.doc Last Saved On: 4/16/99 8:29 AM...

  • Page 41: Country-Specific Requirements

    Industrial Standard C8303 (15A, 125V) configuration. Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installtion Guide Comments: Part Number: 340662-002 File Name: g-appc Power Cord Set Requirements.doc Last Saved On: 4/16/99 8:29 AM...

  • Page 42: Specifications

    50 - 60 Hz Rated Input Current continued Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: h-appd Specifications.doc Last Saved On: 4/16/99 8:32 AM...
  • Page 43 439.4 mm Weight 10.5 lbs 4.8 kg Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: h-appd Specifications.doc Last Saved On: 4/16/99 8:32 AM...
  • Page 44 Fibre Channel Cable 2-15 GBIC Module 2-15 Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: i-index.doc Last Saved On: 4/13/99 9:15 AM...
  • Page 45 Option kit contents 1-2 rack stability ix www.compaq.com x Compaq Confidential – Need to Know Required Writer: Susan Caesar Project: Compaq StorageWorks Fibre Channel Storage Hub 12 Installation Guide Comments: Part Number: 340662-002 File Name: i-index.doc Last Saved On: 4/13/99 9:15 AM...
