ENGINE
ENGINE HEAD REASSEMBLY CONT'D
8. Install breather reed (G) into rocker cover (H).
Lightly apply black RTV sealant to the outer
edges of the breather reed. The reed has a tab
and will assemble one way only. Torque the
breather bolts to 20 ± 5 in. lbs. (2.5 ± 0.55 Nm).
NOTE: When applying RTV, do not get any RTV
inside the reed assembly.
9. Place a new seal (I) into the bottom of the cover.
Be sure the seal is seated into the cover properly.
20 ± 5 in.lbs.
(2.5 ± .55 Nm)
G
REMINDER: Before assembly, clean the bolts and
bolt holes with Primer N (PN 2870585) to remove any
debris. This will ensure proper sealing when installing
bolts.
10. Install rocker cover. Torque bolts to 84 ± 8 in.lbs.
(9.5 ± 0.9 Nm). See Page 3.6 for proper torque
sequence.
Rocker Cover Bolt Torque:
84 ± 8 in. lbs. (9.5 ± 0.9 Nm)
*Torque In Proper Sequence (Pg. 3.6)
3.30
11. Install
thermostat housing. Torque thermostat housing
bolts to 84 ± 8 in.lbs. (9.5 ± 0.9 Nm).
84 ± 8 in.lbs.
(9.5 ± 0.9 Nm)
H
I
12. Install temperature sender (K) and torque to 200 ±
20 in. lbs. (1.4 ± .14 Nm).
thermostat (J), new
J
25 ± 3 ft. lbs.
(34 ± 4 Nm)
Thermostat Housing Bolt Torque:
84 ± 8 in. lbs. (9.5 ± 0.9 Nm)
K
200 ± 20 in. lbs.
(1.4 ± .14 Nm)
K
Temperature Sender Torque:
200 ± 20 in. lbs. (1.4 ± .14 Nm)
O--ring, and
