Install non-DigiSuite cards first!

Installing DigiDesktop

Chapter 2, Hardware Installation
It's important to install any non-DigiSuite cards in your system before
installing your DigiDesktop. If you don't do so, your DigiSuite system
may not work properly.
In addition, try to leave empty slots between your DigiDesktop and non-
DigiSuite cards if it's possible. This will permit additional air flow
between cards.
Important Before removing DigiDesktop from its protective antistatic
bag, place the package within easy reach.
1
Touch a gray metal part of your computer chassis in order to drain
static electricity from your body. Use a grounding wrist strap if you
have one.
2
Remove your existing graphics card (if you already have one in your
system). If slot P3 already contains another PCI card, either move it to
an unused PCI slot or remove it completely.
3
Remove the metal plate located at the back of the slot. Save the screw,
as you'll need it to fasten DigiDesktop after you insert it.
4
Take DigiDesktop out of its antistatic bag and remove the PCI retainer
bracket as explained in "Removing the PCI retainer bracket" on
page 12, if necessary.
5 Carefully align the card with its expansion slot.
6
Slide the card towards the slot until it touches. Make sure that the
metal plate at the back of the card slips into the opening left by the
blank metal plate you removed in step
PCI retainer bracket is aligned with and inserted into the card guide
inside the front of the computer chassis.
7
Once the card is aligned, press it into the slot connector until it's firmly
in place.
8
Secure the card by fastening its metal bracket to the computer chassis
using the screw you removed in step
9 Close your computer cover.
3 above. In addition, be sure the
3 above.
