Figure 8-8. Http Authentication - Lantronix Data Center-Grade Evolution Device Server EDS32PR User Manual

3. On the HTTP Authentication page of the EDS Web Manager, add:
4. Click the Submit button. The EDS creates a username and password to allow the
user to access all web pages located in the directory port1control in the EDS file
system.
Note: The URI, realm, username, and password are user-specified, freeform
fields. The URI must match the directory created on the EDS file system. The
URI and realm used in the example above are only examples and would typically
be different as specified by the user.
EDS Device Servers User Guide
A URI of port1control
A Realm of Monitor
An AuthType of Digest
A Username and Password
Figure 8-8. HTTP Authentication Page
8: Services Settings
80
