XML Configuration
Record: Export System
Configuration Page
Settings
Export XCR data to browser
Export XCR data to the
filesystem
Groups to Export
XML Status Record: Export System Status
If you click XML Status Record at the top of an XML page, the XML Status Record:
Export System Status page displays. Here you can export the current system status in
XML format. The XML data can be exported to the browser window or to a file on the
filesystem.
EDS Device Servers User Guide
Configuration Record: Export System Configuration Page
Figure 11-6. XML Status Record: Export System Status Page
Description
Select this option to export the XCR data to a Web
browser.
Select this option to export the XCR data to a
filesystem. If you select this option, enter a file name for
the XML configuration record.
Check the configuration groups that are to be exported
to the XML configuration record. If no groups are
checked, all groups will be exported.
11: Advanced Settings
119
