Lantronix Data Center-Grade Evolution Device Server EDS32PR User Manual page 138

Category
Dimensions
Weight
Temperature
Relative Humidity
Case
Protocols Supported
Management
Security
Internal Web Server
System Software
LEDs
EMC Standards
Safety Standards
Product Label
Markings
EDS Device Servers User Guide
EDS4100 Specifications (cont'd)
Height: 12.7 cm (5.0 in)
Width: Without mounting brackets 17.65 cm (6.95 in)
Width: With mounting brackets 20.14 cm (7.93 in)
Depth: 3.81 cm (1.5 in)
.86 Kg (1.9 lb)
0 to +55C operating temperature
-40 to +70C storage temperature
10 to 90%, non-condensing
Metal enclosure with removable wall mounts
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP,
Auto IP, SMTP, FTP, DNS, Traceroute, and HTTP
Internal web server, SNMP v2C (MIB-II, RS232MIB), Serial login,
Telnet login, XML
SSL v3, SSH v2
MD5, SHA-1
Rijndael/AES 128-bit encryption
3DES encryption
ARC4 128-bit encryption
Password protection
IP address filtering
Hardened OS and stack
Serves static and dynamic CGI-based pages and Java applets
Storage capacity: 6 MB using industry standard file system
Windows-based DeviceInstaller configuration software and Windows-
based Com Port Redirector
10Base-T and 100Base-TX Link
Ethernet Activity
Serial Transmit Data
Serial Receive Data
Power
Status
FCC CFR 47 Part 15 Subpart B, ICES-003 Issue 4, AS/NZS CISPR
22, VCCI V-3, EN55022, EN61000-3-2, EN61000-3-3, EN55024,
EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-
4-6, EN61000-4-8, EN61000-4-11
UL 60950-1, CSA-22.2 No. 60950-1-03, EN60950-1, CB Report -
IEC 60950-1
FCC Part 15 Statement Class A Device, ICES-003 Class A Device,
C-Tick, VCCI, CE Marking, UL-CUL Mark, TUV-GS Mark
B: Technical Specifications
138
