Syslog Page
Settings
Severity to Log

HTTP Pages

Clicking the HTTP link in the menu bar displays the HTTP Statistics page. This page has
four links at the top for viewing statistics and for viewing and changing configuration,
authentication, and RSS settings.

HTTP Statistics Page

The HTTP Statistics page displays when you click HTTP in the menu bar. It also displays
when you click Statistics at the top of one of the other HTTP pages. This read-only page
shows various statistics about the Hyper Text Transfer Protocol (HTTP) server.
Note: The HTTP log is a scrolling log, with the last Max Log Entries cached and
viewable. To change the maximum number of entries that can be viewed, go to
the HTTP Configuration page (described on page 77).
EDS Device Servers User Guide
Description
From the drop-down box, select the minimum level of system
message the EDS should log. This setting applies to all syslog
facilities. The drop-down list is in descending order of severity
(e.g., Emergency is more severe than Alert.)
Figure 8-6. HTTP Statistics Page
8: Services Settings
76
