Filesystem
Browser Page
Settings
Create
File
Directory
Upload File
Copy File
Source
Destination
Move
Source
Destination
TFTP
Action
Mode
Local File
Remote File
Host
Port
EDS Device Servers User Guide
10: Maintenance and Diagnostics Settings
Filesystem Browser Page
Description
Enter the name of the file you want to create, and then click
Create.
Enter the name of the directory you want to create, and then
click Create.
Enter the path and name of the file you want to upload via
HTTP or use the Browse button to select the file, and then
click Upload.
Enter the location where the file you want to copy resides.
Enter the location where you want the file copied. After you
specify a source and destination, click Copy to copy the file.
Enter the location where the file you want to move resides.
Enter the location where you want the file moved. After you
specify a source and destination, click Move to move the file.
Select the action that is to be performed via TFTP. Choices
are:
Get = a "get" command will be executed to store a file locally.
Put = a "put" command will be executed to send a file to a
remote location.
Select a TFTP mode to use. Choices are:
ASCII
Binary
Enter the name of the local file on which the specified "get" or
"put" action is to be performed.
Enter the name of the file at the remote location that is to be
stored locally ("get') or externally ("put").
Enter the IP address or name of the host involved in this
operation.
Enter the number of the port involved in TFTP operations. Click
Transfer to complete the TFTP transfer.
97
