EDS8/16/32PR

Category
CPU
Flash
RAM
EEPROM
Firmware
Serial Interface
Serial Line Formats
Modem Control
Flow Control
Power Input
Network Interface
Compliance
Dimensions (LxWxH)
Weight
Temperature
Relative Humidity
EDS Device Servers User Guide
EDS8/16/32PR Technical Specifications
EDS8/16/32PR Specifications
®
Intel XScale IXP420 Network Processor running at 266MHz
32k Instruction Cache
32k Data Cache
8 MBytes Flash
32 MBytes SDRAM
2 KB
Upgradable via the Web Manager, TFTP, or FTP
Software-selectable RJ45 serial ports
Software-selectable standard baud rates from 300 to 230k baud.
Customizable baud rate support for non-standard serial speeds.
Data bits: 7 or 8
Stop bits: 1 or 2
Parity: odd, even, none
CTS, RTS, DTR, DSR
Xon/Xoff (software), CTS/RTS (hardware), None
100-240 VAC, 50-60 Hz IEC-type cord
20 Watts
RJ45 Ethernet 10Base-T or 100Base-TX (auto-sensing and hard
coded, auto-crossover), full- and half-duplex
Ethernet: Version 2.0/IEEE 802.3 (electrical)
Ethernet II frame type
30.5 x 43.8 x 434 cm (12 x 17.25 x 1.75 in.), 1U
10 lb maximum
o o
0 to +55 C operating temperature
o o
-40 to +66 C storage temperature
5 to 95%, non-condensing
B: Technical Specifications
139
