Identifying Hardware Components

Figure 3-1 shows the hardware components on the front of the EDS4100. Figure 3-2
shows the hardware components on the back of the EDS4100.
The bottom of the EDS4100 (not shown) has a product information label. This label
contains the following information:
EDS Device Servers User Guide

Figure 3-1. Front View of the EDS4100

Figure 3-2. Back View of the EDS4100

Bar code
Serial number
Product ID (name)
Product description
Hardware address (also referred to as Ethernet or MAC address)
Agency certifications
3: Installation: EDS4100
20
