Navigating Through the Web Manager

The Web Manager provides an intuitive point-and-click interface. A menu bar at the left
side of each page provides links you can click to navigate from one page to another.
Some pages are read-only, while others let you change configuration settings.
Note: There may be times when you must reboot the EDS for the new
configuration settings to take effect. The chapters that follow indicate when a
change requires a reboot.
Figure 6-6
Page
Device
Status
Network
Line
Tunnel
DNS
SNMP
FTP
TFTP
Syslog
HTTP
CLI
Email
SSH
SSL
XML
EDS Device Servers User Guide
shows the structure of the multilevel Web Manager configuration pages.
Summary of Web Manager Pages
Description
Displays EDS product information and network, line, and
tunneling settings.
Lets you configure the current network interface on the EDS.
Displays statistics and lets you change the current configuration
and Command mode settings of 4 serial lines for the EDS4100,
16 serial lines for the EDS16PR, and 32 serial lines for the
EDS32PR.
Displays the current connection statistics and lets you change the
current configuration settings for up to 4 tunnels for the EDS4100,
16 tunnels for the EDS16PR, and 32 tunnels for the EDS32PR.
Displays the current configuration of the DNS subsystem and lets
you change primary and secondary DNS servers.
Displays and lets you change the current Simple Network
Management Protocol (SNMP) configuration settings.
Displays statistics and lets you change the current configuration
for the File Transfer Protocol (FTP) server.
Displays statistics and lets you change the current configuration
for the Trivial File Transfer Protocol (TFTP) server.
Lets you specify the severity of events to log and the server and
ports to which the syslog should be sent.
Displays HyperText Transfer Protocol (HTTP) statistics and lets
you change the current configuration, authentication, and RSS
settings.
Displays Command Line Interface (CLI) statistics and lets you
change the current CLI configuration settings.
Displays email statistics and lets you clear the email log,
configure email settings, and send an email.
Displays and lets you change the configuration settings for SSH
server host keys, SSH server authorized users, SSH client known
hosts, and SSH client users.
Lets you upload an existing certificate or create a new self-signed
certificate.
Lets you export XML configuration and status records, and import
6: Configuration Using the Web Manager
See
Page
40
44
47
52
70
71
72
74
75
75
84
111
111
92
117
