B: Technical Specifications

EDS4100

Category
CPU
Flash
RAM
EEPROM
Firmware
Serial Interface
Serial Line Formats
Modem Control
Flow Control
Power Input
Network Interface
Compliance
EDS Device Servers User Guide
EDS4100 Technical Specifications
EDS4100 Specifications
®
Intel XScale IXP420 Network Processor running at 266MHz
32k Instruction Cache
32k Data Cache
8 MBytes Flash
32 MBytes SDRAM
2 KB
Upgradable via the Web Manager, TFTP, or FTP
4 DB9M serial ports: 2 RS232, 2 RS232/422/485, software selectable
Software-selectable standard baud rates from 300 to 230k baud.
Customizable baud rate support for non-standard serial speeds.
Data bits: 7 or 8
Stop bits: 1 or 2
Parity: odd, even, none
CTS, RTS, DTR, DCD
Xon/Xoff (software), CTS/RTS (hardware), None
9-30 VDC - Barrel connector
42-56 VDC - Screw Terminal
PoE compliant power source - 802.3af (when populated)
RJ45 Ethernet 10Base-T or 100Base-TX (auto-sensing and hard
coded, auto-crossover), full- or half duplex
Ethernet: Version 2.0/IEEE 802.3 (electrical)
Ethernet II frame type
IEEE 802.3af (when PoE is populated)
137
