Protocol Stack Page - Lantronix Data Center-Grade Evolution Device Server EDS32PR User Manual

XML: Import
System
Configuration
Page Settings
Import entire external
XCR file
Import XCR file from
filesystem
Groups and
Instances to Import
Whole Groups to
Import

Protocol Stack Page

Clicking the Protocol Stack link in the menu bar displays the Protocol Stack page. Here
you can configure lower level network stack-specific configuration settings.
Under Current State, there is a Clear link to remove all addresses and a Remove link to
remove the individual address shown. If you click Clear or Remove, a message asks
whether you are sure you want to perform the operation. Click OK to proceed or Cancel
to cancel the operation.
EDS Device Servers User Guide
XML: Import System Configuration Page
Description
Enter the path and file name of the entire external XCR file you want to
import or use the Browse button to select the XCR file.
Enter the filename of the XCR file that has certain groups you want to
import.
If required, enter the filter string for importing specific instances of a
group.
Check the configuration groups that are to be imported into the XML
configuration record. If no groups are checked, all groups will be
imported.
11: Advanced Settings
122
