XML Status Record:
Export System Status
Page Settings
Export XSR data to
browser
Export XSR data to the
filesystem
Groups to Export

XML: Import System Configuration Page

If you click Import XML Configuration Record at the top of an XML page, the XML:
Import System Configuration page displays. Here you can import a system configuration
from an XML file.
The XML data can be imported from a file on the filesystem or uploaded using HTTP. The
groups to import can be specified by toggling the respective group item or entering a filter
string. When toggling a group item, all instances of that group will be imported. The filter
string can be used to import specific instances of a group. The text format of this string is:
<g>:<i>;<g>:<i>;...
Each group name <g> is followed by a colon and the instance value <i>. Each <g>:<i>
value is separated with a semicolon. If a group has no instance, specify the group name
<g> only.
EDS Device Servers User Guide
XML Status Record: Export System Status Page
Description
Select this option to export the XML status record to a Web
browser.
Select this option to export the XML status record to a
filesystem. If you select this option, enter a file name for the
XML status record.
Check the configuration groups that are to be exported into
the XML status record. If no groups are checked, all groups
will be exported.
11: Advanced Settings
120
