Printer Setup - Custom Engineering VKP80II User Manual

INTERFACE ...................................RS232
PROGRAM MEMORY TEST..........OK
DYNAMIC RAM TEST....................OK
EEPROM TEST..............................OK
CUTTER TEST...............................OK
HEAD VOLTAGE [V]
HEAD TEMPERATURE [°C]
PAPER PRINTED [cm]
CUT COUNTER
RETRAC COUNTER
POWER ON COUNTER
RS232 Baud Rate .....................:
RS232 Data Length ...................:
RS232 Parity .............................:
RS232 Handshaking .................:
Busy Condition ..........................:
USB Address Number
USB Status Monitor
Autofeed ....................................:
Print Mode .................................:
Chars / inch ...............................:
Speed / Quality..........................:
Paper Retracting .......................:
Notch Alignment ........................:
Notch Threshold
Notch Distance [mm]
Current ......................................:
Print Density..............................:
[FF] key to enter setup
[LF] key to skip setup
This parameter is displayed if the printer has an USB interface; it's used to identify
(1)
NOTE:
univocally the USB printer by a numerical address code, if on the PC are connected
two printers that are the same models for example two VKP80-UE.
This parameter is displayed if the printer has an USB interface. The Status Monitor
(2)
is an additional printing driver component that allows the printer status monitoring. It
must be enabled only if it was installed the Status Monitor specifi c driver.
If the "Notch Alignment" parameter is "Disabled" this parameter doesn't appear in the
(3)
"Printer Setup" ticket.

PRINTER SETUP

= 23,37
= 25
= 40
= 1
= 0
= 4
(1)
............:
(2)
...............:
(3)
.....................:
(3)
..............:
1. INSTALLATION AND USE
19200 bps
8 bits/chr
None
Xon/Xoff
RcFull
0
Disabled
CR Disabled
Normal
A=15 B=20 cpi
Normal
Disabled
Disabled
2.0V
00
Normal
0%
User Manual
(Fig.1.3)
VKP80II 1-3
