A.1 ACCESSORIES
A.1.1 Power Supply
The fi gure below illustrates the power supply provided by Custom to be used for printer operation.
5
CN1
L
N
FG
-V
-V
+V
+V
4.5
62.0
13.5
6.5
3.4 HOLE
3 - M3 - P 0.5
PPSPS-100-24V
Input specifi cation
Output specifi cation
Environmental condition
Protection devices: Shortcircuit, overload and overvoltage.

APPENDIX A - ACCESSORIES AND SPARE PARTS

193.0
120.0
198.0
158.0
Switching power supply 24V 100W
Input voltage
Current
Input frequency
Output voltage
Output current
Effi ciency
Operating temperature
Humidity
Storage temperature / Humidity
(Fig.A.1)
4 - M3 - P 0.5
RANGE
20.0
8
25
80
250
800
ANGULAR
Note : Dimensioni in mm
85V ÷ 264V
0A ÷ 4.5A
47Hz ÷ 63Hz
24V
0A ÷ 4,5A
80%
0°C ÷ 70°C
20% ÷ 85% Rh (w/o condensation)
-10°C ÷ 75°C/
10% ÷ 95% (w/o condensation)
VKP80II A-1
User Manual
TOLERANCE
B
< 8 0.1
25 0.15
0.25
80
250 0.4
800 0.8
2600 1.5
0.3°
(Tab.A.1)
