In the following table are reported the length recommended for the tickets using of the retracting function:

1.5.6 Notes for installation and lower fastening of printer

3 FIXING POINT (BOTTOM)
ATTENTION
It's very important to consider the screws length to not damage the internal sensor board near
the lower fi xing holes (see fi g. 1.15).
TICKET LENGTH
70 mm
80 mm
80mm ÷ 220mm
1. INSTALLATION AND USE
TICKET PRESENTATION (MAX)
10 mm
10mm ÷ 30mm
10mm ÷ 30mm
+0.5
85.5
-0.5
User Manual
(Fig.1.14)
+0.5
9.5
-0.5
VKP80II 1-11
