1.5 MAINTENANCE

1.5.1 Changing the paper roll

To change the roll of paper, proceed as follows:
1. Position the paper roll so that it unrolls in the direction shown in fi g.1.4.
2. Insert the paper into the paper infeed opening and wait for it to load automatically (see fi g.1.4).
Fig.1.6 gives alignment specifi cations for correct paper loading if no roll holder support is present.
(Fig.1.4)
(Fig.1.5)
WARNING
Before inserting the paper, make sure the cut is straight (see fi g.1.4).
90° 90°
OK
OK
90° 90°
1. INSTALLATION AND USE
VKP80II 1-5
