Paper width adjustment with roll holder support
Paper width may be set from 60mm to 82.5mm max. Rotate the knob to adjust the width of the housing for
paper roll (see fi g. A.10).
(Fig.A.10)
Near paper end adjustment
Rotate the lever to adjust the sensor position for nearly paper end. Move the lever up to in-crease the re-
serve of paper, move the lever down to decrease the reserve of paper (see fi g. A.11).
(Fig.A.11)
"Tie" for roll blocking
Insert the "tie" as shown in fi gure A.12 to avoid the paper roll come out accidentally from the pin.
(Fig.A.12)
