Custom Engineering VKP80II User Manual page 49

Notch on 80 mm paper
Black notch
Notch sensor axis
Notch on 82,5 mm paper
Black notch
Notch sensor axis
26
NON HEAT
SENSITIVE Side
+1
19
0
26
SENSITIVE Side
+1
20,25
0
APPENDIX B - ALIGNMENT MANAGEMENT
80
+0,5
-0,5
82,5
+0,5
-0,5
NON HEAT
Direction
of paper
feed
Direction
of paper
(Fig.B.10)
feed
VKP80II B-7
User Manual
(Fig.B.9)
