  • Page 1 USER AND INSTALLATION MANUAL Onfiniti 5-10 kVA NEW ENERGY NEW ENERGY TO POWER TO POWER www.numericups.com www.numericups.com...

  • Page 2: Table Of Contents

    Table of Contents Safety and EMC Instructions 1-1 Transportation and storage 1-2 Preparation 1-3 Installation 1-4 Operation 1-5 Standards Installation and Operation 2-1 Unpacking and inspection 2-2 Rear panel view 2-3 Single UPS installation 2-4 Software installation Operations 3-1 Button operation 3-2 Led indicators and LCD panel 3-3 Audible alarm 3-4 Single UPS operation...

  • Page 3: Safety And Emc Instructions

    Safety and EMC Instructions Please read the following user manual and the safety instructions carefully before installing the unit or using Connect the earth before connecting to the building wiring terminal. Installation and wiring must be performed in accordance with the local electrical laws and regulations. the unit.

  • Page 4: Installation And Operation

    2. Installation and Operation 2-2. Rear Panel View There are several models for Onfiniti 5-10 kVA. Please refer to the following model table. Model Model 5/6 kVA FM - Standard 7.5/10 kVA FM - Standard 5/6 kVA FM - Standard+1 charger 7.5/10 kVA FM - Standard+1 charger 5/6 kVA FM - Standard+2 charger 7.5/10 kVA FM - Standard+2 charger...
  • Page 5 Diagram 5: 7.5/10 kVA FM Rear Panel Diagram 6: 7.5/10 kVA FM Input/Output Terminal Diagram 9: 7.5/10 kVA FM C Rear Panel Diagram 10: 7.5/10 kVA FM C Input/Output Terminal Diagram 7: 7.5/10 kVA FMI Rear Panel Diagram 8: 7.5/10 kVA FMI Input/Output Terminal Diagram 11: 7.5/10 kVA FMI C Rear Panel Diagram 12: 7.5/10 kVA FMI C Input/Output Terminal...
  • Page 6 External battery connector Wiring spec. (AWG/mm Model RS-232 communication port Input Output Battery Ground Intelligent slot 5/6 kVA FMI - Standard+2 charger 4/16 10/6 10/6 6/10 USB communication 5/6 kVA FMI - Standard+3 charger 4/16 10/6 10/6 6/10 Emergency power off function connector (EPO connector) 7.5/10 kVA FM - Standard 4/16 8/10...

  • Page 7: Software Installation

    • Pay careful attention to the rated battery voltage marked on the rear panel. If you want to change the numbers of the battery pack, please make sure you modify the setting simultaneously. The connection with wrong battery voltage may cause permanent damage of the UPS. Make sure the voltage of the battery pack is correct. •...

  • Page 8: Led Indicators And Lcd Panel

    3-2. LED Indicators and LCD Panel Display Function Backup time information LCD panel Indicates the backup time in numbers H: hours, M: minutes, S: seconds Fault information Indicates warning about fault Indicates the fault codes. The codes are listed in details in section 3-9 Mute operation Indicates that the UPS alarm is disabled LED indicators...

  • Page 9: Audible Alarm

    3-4. Single UPS Operation 1. Turn on the UPS with utility power supply (in AC mode) 3-3. Audible Alarm 1) After power supply is connected correctly, set the breaker of the battery pack at ‘ON’ position (the step Description Buzzer status Muted only available for long-run model).
  • Page 10 battery capacity is more than 25%, the buzzer will beep once every 4 seconds; If the battery voltage 10. Operation in warning status drops to the alarm level, the buzzer will beep quickly (once every sec) to remind users that the battery 1) When Fault LED flashes and the buzzer beeps once every second, it means that there are some problems is at low level and the UPS will shut down automatically.

  • Page 11: Abbreviation Meaning In Lcd Display

    3-5. Abbreviation Meaning in LCD Display 3-6. LCD Setting There are three parameters to set up the UPS. Refer to the following diagram. Abbreviation Display content Meaning Parameter 1 Enable Parameter 1: It’s for program alternatives. Refer to Disable below table for the programs to set up. Parameter 2 and Parameter 3 are setting options or Auto values for each program.
  • Page 12 • 02: Output frequency • 04: Frequency range for bypass Interface Setting Interface Setting 60 Hz. CVCF mode Parameter 2: Output Frequency Parameter 2: Set the acceptable low frequency for Bypass. Setting the output frequency. You may choose following three 50 Hz.
  • Page 13 • 08: Bypass mode setting • 11: Reserved Interface Setting Interface Setting Parameter 2: Reserved OPN: Bypass allowed. When selected, UPS will run at Bypass mode depending on Bypass enabled/disabled setting. FBD: Bypass not allowed. When selected, it’s not allowed for running in Bypass mode under any situations.
  • Page 14 • 15: Inverter voltage calibration • 18: Reserved Interface Setting Interface Setting Reserved Parameter 2: You may choose ‘Add’ or ‘Sub’ to calibrate inverter voltage. Parameter 3: The voltage range is from 0 V to 6.4 V, the default value is 0 V. •...

  • Page 15: Operating Mode/Status Description

    3-7. Operating Mode/Status Description Battery Test Description When UPS is in AC mode or CVCF mode, press ‘Test’ key for Operating mode/status more than 0.5 sec. Then the UPS will beep once and start AC mode Description When the input voltage is within acceptable range, UPS will ‘Battery Test’.

  • Page 16: Trouble Shooting

    Charge the batteries at least Fan failure/Over temperature Beeps every second 7 hours and check capacity. If the Batteries are not fully charged. Battery backup time is shorter problem still persists, contact the Charger failure Beeps every second than nominal value. service center.

  • Page 17: Specifications

    Disposal Frequency Range 46Hz. ~ 54 Hz. @ 50Hz. system Ref standard: ISO 14001:2015 (Synchronized Range) 56Hz. ~ 64 Hz. @ 60Hz. system • After unpacking the UPS and Battery, the removed packaging materials like polythene paper, thermocole 50 Hz. ± 0.1 Hz. or 60Hz. ± 0.1 Hz. Frequency Range /polyethylene, carton box, nylon belt, nylon thread, shall be collected and disposed through authorized (Batt.
