65F
A1 : 1st HDD LED
B. : INFRARED (IR)
D. : SUSPEND CONNECTOR
F. : RESET SWITCH
H. : KEYLOCK
FAN#: Onboard FAN (12V) Connector
JP2: Keyboard Power On
Keyboard Power On
Disabled (default)
Enabled
NOTE 1: If motherboard does not support keyboard power on function, the JP2
will be fixed by jumperwire.
NOTE 2: When the keyboard power on function shows any compatible problem,
choose Disabled and report the keyboard model to your vender/maker.
NOTE 3: Keyboard power on function must be set from the BIOS. Refer to the
"Integrated Peripherals" sector.
JP3: Signal Level Shift Control
Signal Level Shift Control
Factory default setting
(default)
8
A1 A2
- -
+ +
J2
1
1
J3
E
FAN#
FAN1
FAN2
FAN3
J U M P E R
B C
-
+
F H
G
A2 : 2nd HDD LED
C. : POWER SWITCH
E. : SPEAKER
G. : POWER LED
I. : SUSPEND LED
S E T T I N G
D
15
15
I
FUNCTION
CPU FAN
POWER FAN
CHASSIS FAN
JP2
1 3
1 3
JP3
3
1
