SOLTEK SL-65MIV User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
SL-65MIV/65MIV2/65MIV-X/65MIV2-X V1.1

USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-65MIV and is the answer not in the manual?

Questions and answers

Related Manuals for SOLTEK SL-65MIV

Summary of Contents for SOLTEK SL-65MIV

  • Page 1: User Manual

    T h e S o u l C o m p u t e r T e c h n o l o g y SL-65MIV/65MIV2/65MIV-X/65MIV2-X V1.1 USER MANUAL...
  • Page 2 In no event shall Soltek computer inc. Be li- able for any loss or profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental, or con- sequential damages of any kind, even if Soltek computer inc.

  • Page 3: Soltek Computer Inc

    SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chin, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOLTEK KOREA INC. Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,...

  • Page 4: Table Of Contents

    65MIV/65MIV2/65MIV-X/65MIV2-X C O N T E N T CHAPTER 1 INTRODUCTION ............6 1-1 ITEMLIST CHECKUP ................6 1-2 CPU ......................6 1-3 CHIPSET ....................6 1-4 BIOS ....................... 6 1-5 EXTENSION SLOTS ................6 1-6 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER ....7 1-7 MULTI-I/O FUNCTION ................
  • Page 5 65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.2 J3 ....................... 25 2-6.3 CHASSIS PANEL CONNECTOR ............26 2-6.4 FLAT-PANEL DISPLAY CONNECTOR (DVC1) ......... 27 2-6.5 ATX POWER SUPPLY CONNECTOR ..........27 2-6.6 SECOND USB CONNECTOR ............28 2-6.7 SERIAL PORT CONNECTOR ............29 2-6.8 PS/2 MOUSE AND PS/2 KEYBOARD ..........29 2-6.9 IRQ DESCRIPTION ................

  • Page 6: Chapter 1 Introduction

    65MIV/65MIV2/65MIV-X/65MIV2-X CHAPTER 1 INTRODUCTION 1-1 ITEMLIST CHECKUP • Motherboard • Support CD • User’s Manual • Bundle Bonus Pack CD • Bundle Bonus Pack Manual • Temperature Sensor Cable • ATA66/100 IDE Cable • RS232 Cable • FDD Cable 1-2 CPU ®...

  • Page 7: Advanced High-Performance Dram Controller

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-6 ADVANCED HIGH-PERFORMANCE DRAM CONTROLLER • Supports PC133 and PC100 SDRAM and Virtual Channel Memory (VCM) SDRAM up to 3 DIMMs. • 64-bit data width and 3.3V DRAM interface. • Supports up to 1.5 GB memory space. • Different DRAM types may be used in mixed combinations. •...

  • Page 8: Full Featured Accelerated Graphics Port (Agp) Controller

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-10 FULL FEATURED ACCELERATED GRAPHICS PORT (AGP) CONTROLLER • Synchronous and pseudo-synchronous with the host CPU bus with optimal skew control PCI AGP CPU Mode 33/66/100 MHz DDR 3x synchronous. • Support 66MHz 1x/2x/4x modes for AD and SBA signaling. •...

  • Page 9: 1-15.1 Motherboard Layout

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-15.1 MOTHERBOARD LAYOUT --- 65MIV • Default Setting: Intel Celeron 300A/66 MHz VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686A PCI 3 JCD1 JCD2 WOL1...

  • Page 10: 1-15.2 Motherboard Layout

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-15.2 MOTHERBOARD LAYOUT --- 65MIV2 • Default Setting: Intel Celeron 300A/66 MHz VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686B PCI 3 JCD1 JCD2 WOL1...

  • Page 11: Flat Panel Desktop Monitor Support

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-16 FLAT PANEL DESKTOP MONITOR SUPPORT • The VT8605 / 86C370 has the capability of displaying graphics on TFT flat panel desktop monitors using a 12-bit digital interface to an external encoder. The VT8605 / 86C370 also supports autoexpansion and center- ing of all VGA text and graphics modes to ensure that the entire flat panel display will be utilized.

  • Page 12: Chipset Diagram

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-18 CHIPSET DIAGRAM • The VT8605 is a high performance, cost-effective and energy efficient SMA chip set for the implementation of AGP / PCI / LPC desktop personal computer system with 66MHz, 100MHz, and 133MHz CPU host bus (“Front Side Bus”) frequencies and based on 64-bit Socket-370 (Intel Pentium III, Celeron) super-scalar processors.

  • Page 13: Motherboard Specification Table Of 65Miv/65Miv2

    65MIV/65MIV2/65MIV-X/65MIV2-X 1-19 MOTHERBOARD SPECIFICATION TABLE OF 65MIV/ 65MIV2 Model 65MIV 65MIV2 North bridge VIA VT8605 South bridge VIA VT82C686A VIA VT82C686B Supports PC133 and PC100 SDRAM and Virtual Channel Memory Memory (VCM) up to 1.5GB 3 DIMM Slots AGP Interface AGP 4X Mode On-chip S3 SAVAGE 4 AGP 4X...
  • Page 14 65MIV/65MIV2/65MIV-X/65MIV2-X ATTENTION !!! 1. Please refer to your processor installation or other documentation attached with your CPU for detailed installing instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU. Uncorrected installation may result in overheating and damage of your CPU.
  • Page 15 65MIV/65MIV2/65MIV-X/65MIV2-X MEMO...

  • Page 16: Chapter 2 Hardware Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X CHAPTER 2 HARDWARE SETUP 2-1 CPU INSTALLATION WARNING !!! Never run you processor without the heat sink properly and firmly attached. PERMANENT DAMAGE WILL RESULT! 1. Pull the lever sidways away from the socket, and then raise the lever up to a 90-degree angle.

  • Page 17: Memory Installation

    65MIV/65MIV2/65MIV-X/65MIV2-X 3. Make sure that the CPU positions in the socket tightly, and then put the lever down to complete the CPU installation. 2-2 MEMORY INSTALLATION WARING !!! • Make sure that you unplug your power supply when adding or removing memory modules or other system components, failure to do so may cause severe damage to both your motherboard and expansion cards.

  • Page 18: Hdd/Fdd Installation

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-3 HDD/FDD INSTALLATION • To install HDD (Hard Disk Drive), you may connect the cable’s blue connector to the motherboard’s primary (IDE1) or secondary IDE connector, and then connect the gray connector to your slave de- vice and the black connector to your master device. If you install two hard disks , you must configure the second drive to Slave mode by setting its jumper accordingly.

  • Page 19: 2-4.1 Cpu Bus Ratio Select

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-4.1 CPU BUS RATIO SELECT • Normally, the Bus Ratio (Frenquency Multiple) of your processor is locked by processor’s Vendor, setting of the CPU Bus Ratio will have no effect. • Bus Ratio exceed 8.0X, user can not change all values from DIP switch the Bus ratio will be detected by BIOS automatically.

  • Page 20: Jumper Definitions

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-5 JUMPER DEFINITIONS • The figure below shows the location of the motherboard’s jumper blocks. CAUTION • Do not move the jumper with the power on. Always turn off the power and unplug the power cord from the computer before changing the jumper. Otherwise, the motherboard could be damaged.

  • Page 21: 2-5.3 Power Lost Resume (Jp9)

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-5.3 POWER LOST RESUME (JP9) JP9: POWER LOST RESUME Normal (default) Enabled NOTE: This jumper allows user to use the switch of ATX power supply to control ON/OFF switch directly instead of using the power switch on the motherboard. 2-5.4 CLEAR CMOS DATA (JBAT1) JBAT1: CLEAR CMOS DATA Clear CMOS Data...

  • Page 22: 2-5.6 Cd-Rom Audio Connector (Jcd1/Jcd2)

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-5.6 CD-ROM AUDIO CONNECTOR (JCD1/JCD2) JCD1/JCD2: CD-ROM AUDIO CONNECTOR PIN NO. JCD1 JCD2 PIN 1 Left Channel PIN 2 Left Channel PIN 3 PIN 4 Right Channel Right Channel 2-5.7 THERMAL SENSOR CONNECTOR (RT2) RT2: THERMAL SENSOR CONNECTOR a: Connect to RT2. b: Connect this thermal sensor to particular device which generates lots of heat such as...

  • Page 23: Connectors

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6 CONNECTORS • In this section we list all external connectors that user will use them. 2-6.1 J2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 HDD LED CONNECTOR PIN 1 PIN 2 HDD LED SIGNAL PIN 3 HDD LED SIGNAL...
  • Page 24 65MIV/65MIV2/65MIV-X/65MIV2-X 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ATX POWER SWITCH PIN 12 ATX POWER SWITCH PIN 13 The system power is controlled by a momentary switch connected to this lead. Pressing the button once will switch the system between ON and SOFT OFF.

  • Page 25: 2-6.2 J3

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.2 J3 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 SPEAKER CONNECTOR PIN 1 SPEAKER SIGNAL PIN 2 NONE PIN 3 PIN 4 This SPEAKER connector connects to the case- mounted speaker. Two sources (LINE OUT and DESCRIPTION SPEAKER) allow you to hear system beeps and warnings.

  • Page 26: 2-6.3 Chassis Panel Connector

    65MIV/65MIV2/65MIV-X/65MIV2-X 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 SUSPEND LED PIN 14 SUSPEND LED SIGNAL PIN 15 DESCRIPTION Connect to Suspend indicator light. 2-6.3 CHASSIS PANEL CONNECTOR A : PS/2 MOUSE PORT B : USB 0 PORT C : LPT1 PORT D : GAME/MIDI PORT...

  • Page 27: 2-6.4 Flat-Panel Display Connector (Dvc1)

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.4 FLAT-PANEL DISPLAY CONNECTOR (DVC1) • This motherboard provides a special socket “ DVC1 ”. Which has the capability of displaying graphics on TFT flat panel desktop monitors using a 12-bit digital interface to an external encoder. The motherboard also supports auto expansion and centering of all VGA text and graphics modes to ensure that the entire flat panel display will be utilized.

  • Page 28: 2-6.6 Second Usb Connector

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.6 SECOND USB CONNECTOR • This connector is for connecting the additional USB cable. It provides you additional four USB ports. User can order the additional USB cable from your motherboard dealer and vender. Additional USB Cable (Optional) Black Black Green Green...

  • Page 29: 2-6.7 Serial Port Connector

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.7 SERIAL PORT CONNECTOR • One serial port is ready for a mouse or other serial devices. A second serial port is available using a serial port bracket connected from the motherboard to an expansion slot opening. PIN1 VT8605 Serial Port Connectors: 1 2 3 4 5 6 7 8 Orient the red markings on...

  • Page 30: 2-6.9 Irq Description

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-6.9 IRQ DESCRIPTION Function Description Priority IRQ 0 System Timer IRQ 1 Keyboard Controller IRQ 2 Programmable Interrupt IRQ 3 Serial Port (COM 2) IRQ 4 Serial Port (COM 1) IRQ 5 IRQ 6 Floppy Disk Controller IRQ 7 Parallel Port (LPT1) IRQ 8 Real Time Clock (RTC)

  • Page 31: Voice Dianostic Function

    65MIV/65MIV2/65MIV-X/65MIV2-X 2-7 VOICE DIANOSTIC FUNCTION --- ONLY FOR 65MIV-X/ 65MIV2-X • The Voice Diagnostic Function provides user an indispensable assistance on troubleshooting while assembling your computer components. If there is any conflict or other latent problem triggers a boot-up failure, this new VD-TECH technology will voice you realistically where the conflict/prob- lem is, then user can remove the malfunction quickly.
  • Page 32 65MIV/65MIV2/65MIV-X/65MIV2-X JP10: VD-TECH CONTROLLER CHIP JP10 Enabled (default) JP10 Disabled VT8605 1 2 3 4 5 6 7 8 AGP 4X JFAN2 PCI 1 JBAT1 PCI 2 AC'97 Codec VT82C 686A/ 686B PCI 3 JCD1 JCD2 WOL1 JP7/JP8: VOICE DIAGNOSTIC LANGUAGE SELECT Chinese Language English Language (default) Japanese Language...
  • Page 33 65MIV/65MIV2/65MIV-X/65MIV2-X MEMO...

  • Page 34: Chapter 3 Software Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X CHAPTER 3 SOFTWARE SETUP 3-1 ABOUT THE SUPPORT CD • In support CD, it contains most informations for user’s requirement, such as Acrobat Reader, BIOS, User’s Manual, Driver, Hardware Monitor (if motherboard supports this function), Patch, and Utility etc. User can browse the CD and get further details in regard of our motherboard.
  • Page 35 65MIV/65MIV2/65MIV-X/65MIV2-X Step 5: • Press Next button to continue. Step 6: • Click “Yes” to continue. Step 7: • Press select the checkbox as below: Bus Master PCI IDE Driver AGP VxD Driver VIA Chipset Function’s Registry IRQ Routing Miniport Driver Note: In Windows 98SE environment, user does not need to add “VIA Chipset Function’s Registry”...
  • Page 36 65MIV/65MIV2/65MIV-X/65MIV2-X Step 9: • We recommend user to leave “Enable / Disable [Ultra] DMA” checkbox empty. Note: Whether select this item or not, user needs to enable the Hard Disk DMA function in Control Panel manually. (For further details, please refer to next page) Step 10: •...
  • Page 37 65MIV/65MIV2/65MIV-X/65MIV2-X Step 13: • After all the setup process is finished, please restart your computer by clicking on Finish. bout Hard Disk DMA Function Last but not least, user must enable the Hard Disk DMA function. The process is below: 1.

  • Page 38: Onboard S3® Savage4Tm Vga Driver Installation

    65MIV/65MIV2/65MIV-X/65MIV2-X ® 3-3 ONBOARD S3 SAVAGE4 VGA DRIVER INSTALLATION ® • We provide a simple process for user to install the S3 Savage4 VGA driver. Whichever Microsoft Windows operating system user adopts, they have similar installation below. 3-3.1 INSTALL PM133 VGA DRIVER FOR WINDOWS 95/98/SE 1.

  • Page 39: 3-3.3Install Pm133 Vga Driver For Windows Me

    65MIV/65MIV2/65MIV-X/65MIV2-X 3-3.3INSTALL PM133 VGA DRIVER FOR WINDOWS ME 1. Please put the Support CD attached to motherboard into the CD-ROM drive. When appears a welcome window as left screen, then user should choose “Install Driver”. 2. Clock on the “VIA chipsets Driver”. 3.

  • Page 40: Ac'97 Audio Codec Installation

    65MIV/65MIV2/65MIV-X/65MIV2-X 3-4 AC’97 AUDIO CODEC INSTALLATION Step 1: • Please put the Support CD attached to motherboard into the CD-ROM drive. • When appears a welcome window as left screen, then user should choose “Install Driver”. Step 2: • Click on the “VIA Chipsets Driver”. Step 3: •...
  • Page 41 65MIV/65MIV2/65MIV-X/65MIV2-X MEMO...

  • Page 42: Chapter 4 Bios Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X CHAPTER 4 BIOS SETUP 4-1 INTRODUCE THE BIOS • BIOS stands for Basic Input Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory(ROM) chip on the motherboard. BIOS is the first program to run when you turn on your computer.

  • Page 43: What Is Cmos

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-4 WHAT IS CMOS • CMOS is a special kind of memory maintained by a battery after you turn your computer off. The BIOS uses CMOS to store the settings you selected in SETUP. The CMOS also maintains the internal clock. Every time you turn on your computer, the BIOS Looks in CMOS for the settings you se- lected and configures your computer accordingly.

  • Page 44: 4-6.2 Upgrade Process

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-6.2 UPGRADE PROCESS Note: Normally, to upgrade BIOS that is unnecessary if the system is working fine without any problem, user should upgrade the BIOS unless you experienced incompatible problem or need BIOS upgrade to create new features. However, please read all information in this section before upgrading.
  • Page 45 65MIV/65MIV2/65MIV-X/65MIV2-X Figure 1 : Award Flash Memory Writer Start Screen Figure 2 : Award Flash Memory Writer Start Screen...
  • Page 46 65MIV/65MIV2/65MIV-X/65MIV2-X The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS data after programming /r : Reset system after programming NOTE: User can type AWDFLASH /? to get further details about parameters. Wrong usage of parameter will damage the BIOS information, so that we strongly recommend user to leave parameters away unless you realize their function.

  • Page 47: Cmos Setup Utility

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-7 CMOS SETUP UTILITY • This VIA PM-133 motherboard comes with the AWARD BIOS from AWARD Software Inc. Enter the Award BIOS program Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 48: Standard Cmos Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-8 STANDARD CMOS SETUP • Standard CMOS Setup allows you to record some basic system hardware configuration and set the system clock and error handling. You only need to modify the configuration values of this option when you change your system hardware configuration or the configuration stored in the CMOS memory gets lost or damaged.
  • Page 49 65MIV/65MIV2/65MIV-X/65MIV2-X Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the de- sired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the de- sired value into the field.
  • Page 50 65MIV/65MIV2/65MIV-X/65MIV2-X Drive A / Drive B Set this field to the type(s) of floppy disk drive(s) in- stalled in your system. The choices are: 360KB, 5.25in., 1.2MB, 5.25in., 720KB, 3.5in., 1.44MB, 3.5in., Drive A (default) 2.88MB, 3.5in., None., Drive B (default) Video Set this field to the type of video display card installed in the system.

  • Page 51: Advanced Bios Features

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-9 ADVANCED BIOS FEATURES • ADVANCED BIOS FEATURS allows you to improve your system perfor- mance or set up sysem features according to your preference. Run the ADVANCED BIOS FEATURES as following: 1. Choose “ADVANCED BIOS FEATURES” from the Main Menu and a screen with a list of option will appear: 2.
  • Page 52 65MIV/65MIV2/65MIV-X/65MIV2-X CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Advanced BIOS Features Item Help Disabled Virus Warning Menu Level Enabled CPU Internal Cache Enabled External Cache Enabled CPU L2 Cache ECC Checking Disabled Process or Number Feature Enabled Quick Power On Self Test Floppy First Boot Device HDD-0...
  • Page 53 65MIV/65MIV2/65MIV-X/65MIV2-X Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an antivirus program. Keep in mind that this feature protects only the boot sector, not the entire hard drive.
  • Page 54 65MIV/65MIV2/65MIV-X/65MIV2-X First/Second/Third/ The BIOS attempts to load the operating system from Other Boot Device the devices in the sequence selected in these items. The choice: Floppy, LS/ZIP, HDD, SCSI, CDROM, Disabled. Swap Floppy Drive This field is effective only in systems with two floppy drives.
  • Page 55 65MIV/65MIV2/65MIV-X/65MIV2-X Typematic Rate (Chars When the typematic rate setting is enabled, you can / Sec) select a typematic rate (the rate at which character repeats when you hold down a key) of 6, 8, 10, 12, 15, 20, 24, or 30 characters per second. Typematic Delay Choose 250 (default), 500, 750 and 1000.

  • Page 56: Advanced Chipset Features

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-10 ADVANCED CHIPSET FEATURES • ADVANCED CHIPSET FEATURES allows you to change the values of chipset registers. These registers control the system options. Run the ADVANCED CHIPSET FEATURES as following: 1. Choose “ADVANCED CHIPSET FEATURES” from the Main Menu and a screen with a list of option will appear: 2.
  • Page 57 65MIV/65MIV2/65MIV-X/65MIV2-X CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Advanced Chipset Features Item Help Bank 0/1 DRAM Timing SDRAM 8/10ns Menu Level Bank 2/3 DRAM Timing SDRAM 8/10ns Bank 4/5 DRAM Timing SDRAM 8/10ns SDRAM Cycle Length DRAM Clock Host CLK DRAM Drive Strength Auto...
  • Page 58 65MIV/65MIV2/65MIV-X/65MIV2-X Bank 0/1 2/3 4/5 DRAM This item allows you to select the value in this field, Timing depending on whether the board has paged DRAMs or EDO (Extended Data Output) DRAMs. The choice: SDRM 8 / 10ns Normal Medium Fast Turbo SDRAM Cycle Length...
  • Page 59 65MIV/65MIV2/65MIV-X/65MIV2-X Fast R-W Turn Around This item controls the DRAM timing. It allows you to enable / disable the fast read / write turn around. The choice: Enabled, Disabled. System BIOS Choose Enabled or Disabled (default). When enabled, Cacheable the access to the system BIOS ROM addressed at F0000H - FFFFFH is cached.
  • Page 60 65MIV/65MIV2/65MIV-X/65MIV2-X OnChip USB / USB2 This should be enabled if your system has a USB installed on the system board and you want to use it. Even when so equipped, if you add a higher perfor- mance controller, you will need to disable this feature. The choice: Enabled, Disabled.
  • Page 61 65MIV/65MIV2/65MIV-X/65MIV2-X PCI Master 0 WS Write When Enabled, writes to the PCI bus are executed with zero wait states. The choice: Enabled, Disabled. PCI Delay Transaction The choice: Enabled, Disabled. PCI # 2 Access # 1 The choice: Enabled, Disabled(default). Retry AGP Master 1 WS The choice: Enabled, Disabled(default).

  • Page 62: Integrated Peripherals

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-11 INTEGRATED PERIPHERALS • INTEGRATED PERIPHERALS option allows you to get some informations inside your system when it is working. Run the INTEGRATED PERIPHERALS as following: 1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a screen with a list of option will appear: 2.
  • Page 63 65MIV/65MIV2/65MIV-X/65MIV2-X CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Integrated Peripherals Item Help On-Chip IDE Channel 0 Enabled On-Chip IDE Channel 1 Menu Level Enabled IDE Prefetch Mode Enabled Primary Master PIO Auto Primary Slave PIO Auto Secondary Master PIO Auto Secondary Slave PIO Auto...
  • Page 64 65MIV/65MIV2/65MIV-X/65MIV2-X On-Chip IDE channel The chipset contains a PCI IDE interface with sup- port from two IDE channels. Select Enabled to acti- vate the first and/or the second IDE interface. Select Disabled to deactivate an interface if you install a pri- mary and/or second add-on IDE interface.
  • Page 65 65MIV/65MIV2/65MIV-X/65MIV2-X Onboard FDC Select Enabled if your system has a floppy drive con- Controller troller (FDC) installed on the system board and you want to use it. If you install add-in FDC or the system has no floppy drive, select Disabled in this field. The choice: Enabled, Disabled.
  • Page 66 65MIV/65MIV2/65MIV-X/65MIV2-X ECP Mode Use DMA Select a DMA channel for the port. Parallel Port EPP Type Select EPP port type 1.7 or 1.9, as required by your parallel peripheral. Onboard Legacy Audio This field controls the onboard audio. • Sound Blaster •...

  • Page 67: Power Management Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-12 POWER MANAGEMENT SETUP • POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as following: 1. Choose “POWER MANAGEMENT SETUP” from the Main Menu and a screen with a list of option will appear: CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Power Management Setup Enabled...
  • Page 68 65MIV/65MIV2/65MIV-X/65MIV2-X ACPI Function Select Enabled only if your computer’s operating sys- tem supports the Advanced Configuration and Power Interface (ACPI) specification. Currently, Windows NT 5.0 support ACPI. CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Power Management Power Management User Define Item Help HDD Power Down...
  • Page 69 65MIV/65MIV2/65MIV-X/65MIV2-X Doze Mode After the selected period of system inactivity, the CPU clock runs at slower speed while all other devices still operate at full speed. Suspend Mode After the selected period of system inactivity, all de- vices except the CPU shut off. ACPI Suspend Type This item will allow you to select the ACPI suspend type.
  • Page 70 65MIV/65MIV2/65MIV-X/65MIV2-X MODEM Use IRQ Name the interrupt request (IRQ) line assigned to the modem (if any) on your system. Activity of the se- lected IRQ always awakens the system. Soft-Off by PWR-BTTN When Enabled, turning the system off with the on/off button places the system in a very low-power-usage state, with only enough circuitry receiving power to detect power button activity or Resume by Ring...
  • Page 71 65MIV/65MIV2/65MIV-X/65MIV2-X LPT & COM When On of LPT & COM, any activity from one of the listed system peripheral devices or IRQs wakes up the system. HDD & FDD When On of HDD & FDD, any activity from one of the listed system peripheral devices wakes up the system.
  • Page 72 65MIV/65MIV2/65MIV-X/65MIV2-X IRQ Activity Monitor- The following is a list of IRQ’s (Interrupt ReQuests), which can be exempted much as the COM ports and LPT ports above can. When an I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur.

  • Page 73: Pnp / Pci Configuration

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-13 PNP / PCI CONFIGURATION • PNP/PCI CONFIGURATION allows you to set the system’s power saving functions. Run the PNP/PCI CONFIGURATION as following: 1. Choose “PNP/PCI CONFIGURATION” from the Main Menu and a screen with a list of option will appear: CMOS Setup Utility - Copyright (C) 1984-2000 Award Software PnP/PCI Configurations PNP OS Installed...
  • Page 74 65MIV/65MIV2/65MIV-X/65MIV2-X PNP OS Installed Select Yes if the system operating environment is Plug-and-Play aware (e.g., Windows95). NOTE: BIOS will automatically disable all PnP resources except the boot device card when you select Yes on Non-PnP operating system. Reset Configuration Normally, you leave this Disabled. Select Enabled to Data reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-...
  • Page 75 65MIV/65MIV2/65MIV-X/65MIV2-X DMA Resources Press Enter. Please refer to the below list. CMOS Setup Utility - Copyright (C) 1984-2000 Award Software DMA Resources DMA-0 assigned to PCI/ISA PnP Item Help DMA-1 assigned to PCI/ISA PnP Menu Level DMA-3 assigned to PCI/ISA PnP DMA-5 assigned to PCI/ISA PnP DMA-6 assigned to...

  • Page 76: Pc Health Status

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-14 PC HEALTH STATUS • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact with your motherboard supplier to get proper value about your set- ting of the CPU temperature.

  • Page 77: Frequency/Voltage Control

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-15 FREQUENCY/VOLTAGE CONTROL CMOS Setup Utility - Copyright (C) 1984-2000 Award Software Frequency Control Item Help Auto Detect DIMM/PCI CLK Disabled Spread Spectrum Disabled Menu Level CPU Host Clock :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Auto Detect To reduce the occurrence of electromagnetic inter- DIMM/PCI CLK...

  • Page 78: Load Optimized Defaults

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-16 LOAD OPTIMIZED DEFAULTS • When you press <Enter> on this item you get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y / N) ? N ” Pressing “Y” loads the BIOS default values that are factory settings for opti- mal performance system operations.

  • Page 79: Set Supervisor / User Password

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-17 SET SUPERVISOR / USER PASSWORD • These two options allow you to set your sysem passwords. Normally, the supervisor has a higher ability to change the CMOS setup option than the user. The way to set up the passwords for both Supervisor and User are as follows: 1.

  • Page 80: Save & Exit Setup

    65MIV/65MIV2/65MIV-X/65MIV2-X 4-18 SAVE & EXIT SETUP • SAVE & EXIT SETUP allows you to save all modifications you have speci- fied into the CMOS memory. Highlight this option on the Main Menu and the following message appears: “SAVE to CMOS and EXIT (Y/N) ? Y “...
