SOLTEK SL-65F+ User Manual And Technical Manual page 25

PCI / VGA Act-Monitor
Soft-Off By PWR-BTTN
PowerOn by Ring
Wake On LAN
IRQ 8 Break Suspend
Resume by Alarm
Primary INTR
Enabled: The system can not enter the power saving mode
when monitor is on.
Disabled (default): The system can enter the power saving
mode when monitor is on.
Instant-Off (default): Turn off the system power at once after
Delay 4 Sec: Turn off the system power 4 seconds after push-
ing the power button (to meet PC97/98 spec)
When user sets Enabled, a signal from ring returns the sys-
tem to Full On state.
The choice: Enabled, Disabled (default).
Enabled: Wake on the system from the LAN card (LAN card
must support wake on LAN function and the power
supply must provide at least 5V/7750mA standby
current)
Disabled(default): Disable Wake On LAN function.
You can enable or disable monitoring of IRQ 8, so that it doesn't
awaken the system from suspend mode.
The choice: Enabled, Disabled (default).
Enabled: Wake up the system at assigned time, and also,
then user needs to set both "Date Alarm" and "Time
Alarm" options.
Disabled (default): Disable this feature.
When set to On, any event occurring at will awaken a system
which has been powered down.
On(default): The system can not enter the power saving mode
when I/O ports or IRQ# is activated.
Off: The system still can enter the power saving mode when
I/O ports or IRQ# is activated.
pushing the power button.
65F+ BIOS
25
