APPENDIX C
Thermal Sensor Connector
VIA Hardware Monitor Setup
1. Make sure that the CD is in the CD-ROM.
2. There will appear a welcome window, please use the mouse to choose
"Install Driver" item.
(If not, that means user's CD-ROM autorun function is disabled, but user
could still install the program via Windows Explorer. )
3. Choose "Install VIA Chipset Driver" item, then choose "Install VIA
Hardware Monitor" item.
4. The setup program will install Hardware Monitor software automatically.
THERMAL SENSOR
a: Connect to RT2.
b: Connect this thermal sensor to
particular device which gener-
ates lots of heat such as Hard
Disk, VGA chip, etc. When
connected, user could observe
the temperature change from
the BIOS program.
Appendix C
39
